Technical Data TD450014EN facility communications expansion options facility communications system 2 4 Options 2 zone Class A or 4 zone Class B speaker audio splitter 5 audio boosters 6 7 diagram 8 9 addressable paging splitter and telephone zone controller 10 supervised volume control and remote microphone 11 microphone expansion module 12 13 and engineers specifications 14 16 February 2016 Supersedes October 2014SAFEPATH Product Linefirealarmresources com Data TD450014EN February 2016 Facility Communications SP40S is a multifunction supervised paging messaging music BGM delivery and emergency voice evacuation with 24 VDC battery backup The SP40S integrates with fire systems and provides full control of building audible and visual appliances This single channel system is capable of 40 watts of supervised high fidelity audio power and amps of supervised 24 VDC synchronized strobe power It comes with an on board digital voice messaging system with standard messages a hand held microphone power supply charger and numerous additional features The SAFEPATH is expandable to 5280 watts utilizing the SPB 80 4 80 watts 4 amps of strobe power the SPB 160 160 watts or SPB 320 watts supervised audio power boosters All models are in 115 VAC or 220 VAC when combined with audio boosters and Wheelock LSPK LSPST S and EH product lines meets both NFPA fire signaling and NFPA 720 CO signaling low frequency tone for sleeping areas evacuation Supervised NAC speaker and strobe circuits Live microphone override 8 digitally pre recorded voice messages Selectable pre tones for messages music Capable of broadcasting from a supplied BGM source Unique supervision method allows for full system supervision during background music Line Level input for music source Frequency Response 100Hz paging Easily interfaces with most existing phone system page port port and line level signals Automatically mutes BGM Frequency Response 275 5kHz Night ringer or security alert connection inputs and activation 2 Amps of 24 VDC supervised strobe power with built in sync protocol Power limited Strobe output is selectable for control of Wheelock sync or non sync operation Strobe terminals have pass through capability for Wheelock sync non sync operation Any of the 8 messages can be dip switch selected to strobes strobes strobes Microphone activation can be dip switch selected to Auxiliary activation Remote MIC can be dip switch selected to output 40 watts of supervised audio power Speaker outputs 25V or 70 7V power limited activation Contact closure message activation processing Volume and tone controls for general paging and BGM Connectivity of optional speaker splitter modules Dual tone tone generator with Code 3 Tone and Slow Whoop alerting of system trouble Night ringer security alerting capability Audio power can be expanded by connecting to optional audio boosters SPB 80 4 80 watt supervised audio power booster with Amp of Synchronized Strobe Power SPB 160 160 watt supervised audio power booster SPB 320 320 watt supervised audio power booster pre recorded message announcement Supplied with 8 pre recorded emergency messages Capable of in field recording of all messages via 1 8 line level input jack Preset audio levels for emergency messaging prerecorded and mic reverts back to a preset level regardless of volume set for BGM or general paging On board push to talk microphone Telephone paging input disconnects BGM when in use Auxiliary input for remote microphone connection supply batteries 24 VDC 33AH max rechargeable battery back up power built in Batteries can be housed in the enclosure Up to two BAT 1212 volt 12 ampere hour batteries can fit in the enclosure Actual size required will depend on speaker and or strobe load are sold separately CAUTIONS and WARNINGS are identified by the symbol warnings are printed in bold capital letters WARNING READ THESE SPECIFICATIONS AND ASSOCIATED INSTALLATION CAREFULLY BEFORE USING SPECIFYING OR APPLYING PRODUCT FAILURE TO COMPLY WITH ANY OF THESE INSTRUCTIONS OR WARNINGS COULD RESULT IN IMPROPER APPLICATION AND OR OPERATION OF THESE PRODUCTS IN AN SITUATION WHICH COULD RESULT IN PROPERTY DAMAGE SERIOUS INJURY OR DEATH TO YOU AND OR OTHERS advantages One multi function in building communications system Background Music BGM system with patent pending during BGM operation 24 VDC supervised and synchronized strobe power can be to meet the requirements of the installation via to optional Wheelock power boosters Supervised emergency fire voice evacuation system with telephone system for general paging requirements www eaton comSAFEPATH Product Linefirealarmresources com Data TD450014EN February 2016 two months or the required spare parts inventory Wide ranging applications small to large facilities Can connect to pagers for private alerting of emergency conditions maintenance Multiple trouble LED indicators for quick system diagnostics Fully supervised circuitry always in effect during BGM and paging via patent pending technology Removable quick connect disconnect terminals for ease of wiring 12 to 22 AWG Power limited circuitry with Class or Class wiring only with use of audio splitter Surge protected circuitry Audio and strobe power limiter reset button Wheelock Products All Wheelock speaker strobes All Wheelock strobes All Wheelock speakers All cluster speakers Wheelock strobe power supply Built in power for visual notification appliances e g strobes Expandable for larger system requirements optional equipment compliances Approvals UL Standard 864 9th edition UL Standard 1711 State Fire Marshal CSFM New York City MEA Part 15 To meet both NFPA 72 and NFPA 720 low frequency tone for sleeping areas SAFEPATH is listed to UL 2017 4 UL 864 code 3 and the low frequency requirements of 464 520 Hz OSHA 1910 165 and ADA Compliant 1 year warranty Multi use applicationse The system can function as an system an emergency messaging system a paging an employee notification system and a background music per NFPA 72 Fire code applicationse The system is listed under UL Standard 9th edition delivering supervised audio and voice messaging strobes and notification appliance circuits NAC for visual Economic OSHA applicationse The system is OSHA 1910 165 and therefore it does not require reliability inspections 1 Inputse Audio Activation
