Wheelock STH weatherproof cluster speaker data sheet TD450167EN

Technical Data TD450167EN weatherproof cluster speakers one RSSWP strobe Canada Wheelock STH weatherproof cluster speaker with RSSWP strobe is designed for indoor outdoor ceiling mount in high ambient noise environments It is available with 2 3 or 4 for wide area coverage The cluster speaker strobe is sup with STH 15SR ULC ULC listed under CAN ULC S541 M87 and one RSSWP 24MCCH UL listed under CAN ULC S526 07 strobe mounted to a NEMA 4X non metalic enclosure The is synchronizable The STH weatherproof cluster speaker with strobe comes fully assembled with four STH 15SR horns and one RSSWP strobe The strobe has the following options with three STH 15SR horns and one RSSWP strobe The strobe has the following options Red with no lettering Red with FIRE lettering White with no lettering White with FIRE lettering Red with no lettering Red with FIRE lettering White with no lettering White with FIRE lettering Red with no lettering Red with FIRE lettering with two STH 15SR horns and one RSSWP strobe The strobe plate has the following options with two STH 15SR horns and one RSSWP strobe designed for corner mount The strobe the following options Red with no lettering March 2020Wheelock STH Weatherproof Cluster Speakers Canada firealarmresources com Data TD450167EN March 2020 for use in manufacturing plants and with high ambient noise levels and for required fire life safety applications Hazard warning alerting Process control area notification Warning lights Security alert indication Emergency notification Employee notification audible and visual signaling benefits STH 15SR ULC Speakers are ULC Listed under CAN ULC RSSWP 24MCCH is ULC Listed under CAN ULC S526 Compliant with Canadian Standard for the Installation of Fire Systems CAN ULC S524 and the Canadian Electrical Code 1 Cluster and strobe wiring can be monitored for integrity by the panel Cluster speaker strobes come fully assembled High efficiency unit for fire life safety and or general announcing notification Provides for high intelligibility voice reproduction and high intensity alerting for emergency life safety applications alarm and signaling Speakers and strobes are prefabricated to a 15.5 x 13.5 x 7 4X non metalic enclosure for indoor outdoor use Mounts to ceiling Only 1 pair of wires needed for audio connections Strobes are connected to the NAC strobe circuit and are 115 or 177 candela Each individual STH 15SR ULC horn is capable of delivering up to dB at 15 watts at 10 feet Cluster speakers deliver omni directional sound Conduit knockouts for 1 2 or 3 4 coupling read these specifications and associated installation before using specifying or installing this product Eaton com massnotification for current installation instructions notes Horn Loudspeakers ULC Listed under CAN ULC S541 M87 Supervised weatherproof horn speaker Up to 15 watts RMS of power handling capability Superior intelligibility and sound dispersion Built in 25 70 Volt transformer with screwdriver adjustable tape selector Frequency response 400 Hz Power taps 25 Volts 0.48 0.94 1.83 7.0 and 13.9 70 Volts 0.9 1.8 3.8 7.5 and 15 Swivel mounted for easy angle adjustment Refer to Data Sheet TD450156EN for detailed specs on horn Strobe ULC Listed under CAN ULC S526 07 High intensity selectable 115 or 177 candela ceiling strobe Factory setting is 177 candela Synchronizable when used with DSM or Wheelock power or Wheelock SAFEPATH 24 VDC input voltage 2 Wire connection Current draw 24 VDC 115cd Strobes produce 1 flash per second over the regulated Refer to Data Sheet TD450112EN for detailed RSSWP strobe range www eaton comWheelock STH Weatherproof Cluster Speakers Canada firealarmresources com Data TD450167EN 2020 1 Specifications and ordering information a Number CAN Plate with no lettering with FIRE lettering with no lettering with FIRE lettering with no lettering with FIRE lettering with no lettering with FIRE lettering with no lettering with FIRE lettering with no lettering with FIRE lettering speaker strobe supplied with four STH 15SR ULC horns and one RSSWP ceiling strobe mounted to a NEMA 4X non metalic enclosure speaker strobe supplied with three STH 15SR ULC horns and one RSSWP ceiling strobe mounted to a NEMA 4X non metalic enclosure speaker strobe supplied with two STH 15SR ULC horns and one RSSWP ceiling strobe mounted to a NEMA 4X non metalic enclosure speaker strobe supplied with two STH 15SR ULC horns mounted adjacent to other designed for a corner mount configuration and one RSSWP 24MCCH ceiling mounted to a NEMA 4X non metalic enclosure The weatherproof cluster speakers with RSSWP strobe are a special order Please consult Customer Service for part number set up and lead time information and engineers specifications cluster speaker strobe shall be the STH 15SR ULC with RSSWP 24MCCH Strobe or approved equal The cluster speaker strobe shall be for indoor outdoor ceiling mounting for high ambient noise environments The speaker strobe shall be supplied with ULC listed and one ULC listed ceiling strobe mounted to a NEMA 4X non metalic enclosure The strobe shall be a selectable 115 or 177 candela strobe The cluster speaker and strobe shall be fully assembled The cluster speaker and strobe shall be capable of use for UL Fire Life Safety applications The cluster speaker and strobe wiring shall be able to be monitored for integrity by the control panel speaker horns shall measure 7.87 x 8.75 x 9.32 each and shall be prefabricated on the sides of a 15.5 x 13.5 x 7 enclosure Strobe shall be a high intensity selectable 115 or 177 candela ceiling strobe with a current draw of 0.300 amps for 115cd 24 VDC or amps for 177 cd 24VDC and shall be prefabricated on the bottom of the enclosure of the cluster speaker strobe shall be accomplished by using pre drilled holes on the enclosure to continuous development of our products specifications and offerings are subject to change without notice in accordance with Cooper Inc dba Eaton standard terms and conditions ENCOURAGE AND SUPPORT NICET CERTIFICATION WARRANTY is a registered trademark All other trademarks are property of their respective owners Eaton1000 Eaton BoulevardCleveland OH 44122United StatesEaton comEatonLife safety mass notification solutions273 Branchport Ave Long Branch NJ 07740Eaton com Lifesafetynotification 2020 EatonAll Rights ReservedPrinted in USAPublication No TD450167ENMarch 2020Wheelock STH Weatherproof Cluster Speakers Canada firealarmresources com
