Autocall TrueAlarm Analog Sensors Model A4098-9793, IDNet Isolator Base

Datasheet Analog Sensing Analog Sensors Model A4098 9793 IDNet Isolator Base base wiring suspected to have earth faults can be isolated to in their discovery and repair ULC CSFM Listed FM base for TrueAlarm analog sensors using IDNet communications Compatible with Autocall 4007ES 4010ES or 4100ES Series fire alarm panel IDNet Signaling Line Circuits SLCs providing IDNet 2 or 2 2 output loops see Multi Floor Isolator Example 1 and Multi Isolator Example 2 Can be installed up to 250 total allowing isolation directly to the device Operation is for ceiling or wall mounting Base mounted LED indicates sensor status Designed for EMI compatibility UL listed to Standard 268 ULC listed to Standard S529 circuit wiring isolation Input is automatically separated from output when an output short circuit occurs fault isolation reduces time to fix wiring problems Built in control panel diagnostics assist in locating earth fault the most common installation wiring problem base A4098 9793 is compatible with Photoelectric sensor model A4098 9714 Heat sensor model A4098 9733 Multi sensor model A4098 9754 Class B or Class A wiring Communications are received from either input or output allowing with Class A wiring to isolate short circuits while still operating sensors Sensing and IDNet communication isolation A4098 9793 IDNet Communications Isolator Base provides TrueAlarm analog sensor operation and also provides IDNet isolation to improve installation convenience and system integrity Isolation is automatically activated at the when an output short circuit is detected and isolation can also selected per base manually from the control panel to assist with wiring problems bases power up in isolation mode and are directed to connect the control panel If the output wiring is acceptable the isolator base connect to the rest of the circuit If the output wiring is shorted the remains isolated Tracking isolator reports back to the panel when it is in isolator mode and extent of shorted wiring is reported back to the panel by identifying addresses that are not communicating Isolators are assigned to low number addresses to expedite Signaling Line Circuit power up Refer to Installation Instructions 574 709AC and for additional information Faults installation earth faults often occur and finding these faults requires extensive wiring disconnection With the A4098 9793 1 Channel with a Single A4098 9793 Isolator 4100ES Fire Alarm Control Panel shown for reference This product has been approved by the California State Fire Marshal CSFM pursuant to Section 13144.1 of the California Health and Safety Code See CSFM Listings 7300 2269 0538 7270 2269 0512 ans 7300 2269 0506 for allowable values and or conditions concerning material presented in this document Additional listings may be applicable contact your local supplier for the latest status Rev 11 03 2021 Analog Sensors Model A4098 9793 IDNet Isolator Base Isolator Example 1 one line diagram on this page shows a multiple floor example with Class B IDNet communications for each floor starting at an isolator base If any wiring beyond the isolator base should experience a short circuit each floor can be individually separated from the next preventing the short from disabling the entire IDNet communications wiring the event of an earth connection each floor can be individually isolated using the built in control panel diagnostics With individual floor control the fault can be isolated to the floor level to narrow the search area Notes Operation of the 4090 9793 TrueAlarm Isolator base requires connection to a compatible 4007ES 4010ES or 4100ES IDNet communications Maximum line resistance between the panel and an isolator and between two isolators is 10 or 780 ft 238 m with 18 AWG wire This is a one line drawing showing only IDNet communications wiring Some IDNet devices require additional wiring for power Refer to specific devices for details 2 Rev 11 03 2021 Analog Sensors Model A4098 9793 IDNet Isolator Base Isolator Example 2 illustration below is a modification of Example 1 Wiring for each floor has an additional isolator base and the IDNet circuit is wired as a Class A With the addition of these isolator bases wiring between floors can be better protected in the event of a short circuit Also in the event of earth connection the additional isolator base per floor allows earth fault isolation to be achieved with better precision Assistance Communications from an IDNet output provide individual short circuit isolation and allow individual output control to provide in locating wiring faults When wiring Class A IDNet communications provided by IDNet outputs locate isolators as the first and last devices in the loop close to the to provide loop short circuit isolation operation as shown below Notes Operation of the A4098 9793 TrueAlarm Isolator Base requires connection to a compatible 4007ES 4010ES or 4100ES IDNet communications Maximum line resistance between the panel and an isolator and between two isolators is 10 or 780 ft 238 m with 18 AWG wire This is a one line drawing showing only IDNet communications wiring Some IDNet devices require additional wiring for power Refer to specific devices for details 3 Rev 11 03 2021 Information Analog Sensors Model A4098 9793 IDNet Isolator Base 4 Rev 11 03 2021 Analog Sensors Model A4098 9793 IDNet Isolator Base for additional information refer to Installation Instructions 574 709AC and 574 707AC and Communications Specification communications one address per base line resistance between panel and isolator or between isolators is 10 ohms 18 AWG 0.82 mm2 ft 238 m terminals for in out wiring 18 to 14 AWG 0.82 to 2.08 mm2 Connections Listed Temperature Range F to 100 F 0 C to 38 C Temperature Range 15 F to 122 F 9 C to 50 C Temperature Range F to 140 F 18 C to 60 C Range to 95 RH from 32 F to 122 F 0 C to 50 C Color White A4098 9793 or Black A4098 9777 1 Sensor Compatibility sensors are ordered separately Photoelectric Sensor Photoelectric Sensor Heat Sensor Heat Sensor TrueSense Multi Sensor TrueSense Multi Sensor Remote IDNet Isolator Module 24 V Addressable Power Isolator Sheet 2 Additional Isolator Products 5 Rev 11 03 2021 Analog Sensors Model A4098 9793 IDNet Isolator Base 2021 Johnson Controls All rights reserved All specifications and other information shown were current as of document revision and are subject to change without notice listings may be applicable contact your local Autocall product supplier for the latest status Listings and approvals under Tyco Fire Security GmbH and the names listed in this material are marks and or registered marks Unauthorized use is strictly prohibited NFPA 72 and National Fire Alarm Code are registered of the National Fire Protection Association NFPA Rev 11 03 2021
