Cornell Communications Status Lights L-Series

Light Status Status Lights Series Cornell L Series Light Status lights offer 1 6 colors Red Blue Amber Yellow or White to indicate the status of one of Cornell Status Series room status stations The station will wire to one of Cornell S series stations to turn the incandescent lamp when the station is in mode The satin finish stainless steel faceplate with silk screened designations may be flush on a standard outlet box with single gang plaster ring or surface mounted on a Wiremold or equivalent Specifications The contractor shall furnish and install Cornell L Series Room Status at the noted locations for use as indication for S series stations Faceplates shall be satin stainless steel Indicator lamps shall be specified colors to coincide with S series stations For mounting back box shall be standard outlet box with single gang plaster ring for surface Wiremold 5748 or equivalent Information Power Requirements 24VDC Operating Environment 50 120 0 60 Indoor Non condensing Physical Faceplate Dimensions 4 x 2 1 Gang Mounting Single Gang back box with 1 minimum depth Wiring Minimum 22AWG
