DTK SL Series Block Quick Connect Surge Protection Product Specifications Guide SL A 150mA current DTK SL B 2A current suffix denotes UL497A Listed suffix denotes UL497B Listed Service Voltage 30V 50V 95V 130V DTK SL30A DTK SL130B Data DITEK Snap Lite quick connect line protector The Snap Lite provides both and current limiting in addition to surge The unique multi function diagnostic shows protection status line continuity and usage Available in four different voltages is a Snap Lite for virtually any analog 66 application Series Features Quick connect module no bridge clips required Each Snap Lite protects one pair Field replaceable Self resetting fusing Models available for both current limited and lines Features Approvals UL497A UL497B Method Stab connection to 66 Block Continuous Current 150mA A models B models Surge Current 1,000 Amps per pair 30V Amps per pair 50V Amps per pair 75V 130V Modes Tip Ground Ring Ground Temperature 40 158 40 70 Humidity 95 non condensing 1.56 x 3.24 x 38 x 82.3mm x 9.6mm 5oz 14g High Impact Plastic Ten Year Limited Warranty Ground Bus part number DTK SIGB Each 66 Block requires one ground bar DITEK Center Starkey Road FL 33771 Support 1 888 472 6100 Number SPS 100055 001 Rev 2 2 12 DITEK Corp Subject to Change
