DTK TSS3 Surge Solution Panel Protection for Signaling And Notification Lines Product Specifications Total Surge Solution TSS is a of products that provide total surge alarm systems TSS3 is a perfect fit for building to notifier and communications It comes with a prewired four pair base protector Selecting 5V 75V DTK modules or 2MHTP provides a custom solution for system The TSS3 protects four of SLC IDC or NAC circuits All modules are field replaceable shown with 2MHLP Data Protection Modules included Features Surge protection for NAC IDC SLC and circuits 20kA surge rated low voltage suppression Field replaceable surge modules 2MHLP low voltage modules protect two data signal each The TSS3 with two 2MHLP modules protects power and up to 4 data signal pairs Ten Year Limited Warranty Voltage Protection Features Hard wire base for replaceable suppression modules low voltage modules protect two data signal each The TSS3 with 2MHLP modules can up to four data signal pairs Available voltages 5VDC 130VDC Maximum continuous current 5A per module DTK 2MHLP listed to UL497B DTK 2MHTP listed to UL497A NEMA 4X Enclosure for installation in direct spray corrosive environments Weight 4 lb 1.8 kg Dimensions 7 x 4 x 4 Operating temperature 40 F to 175 F to 80 x 102 x 102mm Replacement custom modules DTK 2MHLP required voltage Replacement custom modules DTK 2MHTP lines DTK 2MHLPTM Test Bridging module See DTK 2MHLP DTK 2MHTP Datasheets detailed specifications on SLC IDC NAC Protection DITEK Center Starkey Road FL 33771 Direct 1 727 812 5000 Support 1 888 472 6100 Number SPS 100006 001 Rev 6 2 08 DITEK Corp Subject to Change
