Architect and Engineer Specification Modules Listed S2203 Approved 0B4A6 AY 7165 0900 115 York City MEA266 97 E Loop Module 10 2203 Relay Module 10 2204 Supplemental Loop Module provides two communica circuits which can support up 127 detectors and or modules circuit 254 total The SLM in the Cheetah control to 4 communication loops a maximum of 508 points two SLM communication loops are functionally identi to the communication loops on the main board Power Supply 10 2201 X Cheetah Relay Module CRM4 provides four relays relay is independently programmable and rated for 30Vdc or 0.5A 120Vac The Cheetah supports up 2 CRM4 modules Reverse Polarity Module 10 2254 Supplemental Power Supply SPS adds an additional amps of useable current and supports up to 65 Ah of battery capacity By addition of a SPS the Chee is increased to 10 amps of useable current and 130 Ah standby battery capacity The SPS also provides two 2 power circuits rated for 2A each Due to parallel with Cheetah s main board the SPS may use the batteries on the Cheetah main board as its backup source Also the SPS s current supply may be used the Cheetah main board for use on auxiliary power cir or Notification Alarm Circuits The SPS is available in versions 1 uses a 120Vac step down transformer and uses a 208 240Vac step down transformer Cheetah Reverse Polarity Module CRPM provides reverse polarity NFPA 72 Remote Station outputs on single card The outputs are programmed for one of two either 1 alarm trouble on one output with super on the other output or 2 alarm on one output with on the other output The CRPM occupies the space one CRM4 module All 4 modules are installed onto the main Cheetah and require no separate enclosure Mounting is included when ordering the module S 10th Street P O Box 610 cid 127 Blue Springs Missouri 64013 0610 U S A cid 127 816 229 3405 cid 127 Fax 816 229 0314 cid 127 www fike com 2002 Issue page intentionally left blank Fike Corporation All rights reserved No previously 1145 are subject change without notice
