REMOTE LED ANNUNCIATOR GP 5RA Fike GatorPro GP 5RA is a five zone remote annunciator that mounts onto standard single gang box and provides LED indication for five zones A Local Sounder Silence switch is also provided All LED wiring is supervised trouble condition will cause the System Trouble LED to illuminate GP 5RA Remote Annunciator requires the use of a LED interface module communicate zone trouble conditions from the FACP back to the GP 5RA wiring is supervised for open conditions by this module Use the ADM 24 module to communicate between the GP 5 GP 5UD FACP and the GP 5RA Refer to the appropriate FACP manual for information on mounting ADM 24 to the main circuit board GP 5RA mounts on a standard single gang box and provides LED of the zones in alarm Blank slide in labeling is provided to identify 1 5 Zone 1 RED LED Zone 2 RED LED Zone 3 RED LED Zone 4 RED LED Zone 5 RED LED Trouble YELLOW LED Listed S3271 Local Trouble sounder and Re sound Tone Silence switch is provided All LED wiring is supervised for open Any open condition will cause the System Trouble LED to illuminate and the Local Trouble sounder to buzz the Re sound Tone Silence switch to Silence to turn off the buzzer Once the trouble has been resolved reset the switch to Re sound to enable the warning buzzer for the next trouble If the switch is not reset to Re sound the buzzer will sound again warning you to reset the switch LINE INFORMATION Fike P N 27 010 Five zone Remote Annunciator mounts to a single gang box ADM 24 Fike P N 27 004 Fike P N 27 004 Annunciator Driver Module S 10th Street P O Box 610 Blue Springs Missouri 64013 0610 U S A 816 229 3405 816 229 4615 www fike com No D 1.05.01 THE GP5 RA TO A SINGLE GANG BOX Fike Corporation All Rights Reserved No D 1.05.01 July 2005 Specifications are subject to change without notice
