DARWELL TECHNOLOGY SYSTEMS INC 9315 ETHERNET HTTP SERVER SMTP FTP HOST RS232 RS422 RS485 CVNET CVNET IN CVNET OUT SERIAL CONSOLE MENU DRIVEN VT 100 TERMINAL DIGITAL XPANDER DIAL UP APPS E ade in merica Grisham Drive Texas 75088 1 972 840 1990 1 972 840 1980 Page WWW DARWELL COM Powerware Plus 9315 UPS MC PwrPlus9315 MC PwrPlus9315 is specially designed to interface with an Exide Powerware Plus series UPS The protocol interface provides a user with a full view of the UPS and alarms in real time using a PC equipped with our Windows based SitePro or any html compatible web browser The MC PwrPlus9315 communicates to the UPS while the UPS is in Computer mode over a 3 wire RS232 interface the MC PwrPlus9315 is connected to an Ethernet network and given a proper IP it will begin to serve up custom web pages These web pages give any user to the current status alarm and meter information The MC PwrPlus9315 is capable of transferring alarms data files to two FTP servers that allows monitoring separate SitePRO terminals This unit can also send emails automatically when a alarm is set or cleared MC PwrPlus9315 can be installed in two different configurations Both configurations available in the standard molded plastic enclosure shown above The first option is a desk installation that utilizes the four self adhesive rubber feet Option two uses the enclosed bracket to attach the MC PwrPlus9315 to wall In either configuration the MC should not be more than fifty feet from the UPS matter what installation option is chosen the MC PwrPlus9315 was designed with ease of in mind All board terminations are made with modular connectors and use standard Every MC PwrPlus9315 is shipped with a three foot pigtail host cable and a 110 24 transformer All other cables are optional The MiCore Manual should be consulted before any installation is Defaults Specifications Address Mail Ips Address 1 Offsets 0 Baud Rate 9600 Username Password Key Name Name AC Number Voltage Current Ports Port Ports Baud 8 N 1 9600 Baud 8 N 1 F RH Non condensing Wiring Specifications CONNECTOR CONDUCTORS ETHERNET HOST CONSOLE CVNET MODEM 5 SHIELDED 5 SHIELDED SHIELDED SHIELDED SHIELDED C P w r P l u s 9 3 1 5 P o i n t L i s t 704 S 10th Street Blue Springs MO 64015 Phone 816 229 3405 Fax 816 229 0314 E mail fpssales fike com www fike com
