Fike P 1 49 01 Sync Circuit Module

Sync Module Sync module manufactured by System Sensor synchronizes Fike at 1 Hz and horns at temporal 3 over a single pair of wires Patented technology also allows the silencing of horns on horn strobe models a pair of wires Sync module is designed to power and synchronize either two 3 amp wired in Class B or one 3 amp circuit powered as Class A Should more two zones require synchronization additional modules can be added by the input and output terminals between modules Sync module is also designed to generate temporal 3 tone for Fike and Mini Alert sounders Existing installations can be upgraded to with NFPA 72 FEATURES SPECIFICATIONS Two wire operation from module to the devices Silences horns over a two wire loop Synchronizes strobes at 1 Hz Synchronizes horns to temporal 3 pattern Patented technology Allows slave module operation Generates synchronized temporal 3 tone for Multi Alert and Mini Alert Dimensions 5 1 4 L X 5 1 4 W Mounting 4 11 16 X 4 11 16 X 2 1 8 back box Indoor Operating Temperature 32 to 120 F 0 to 49 C Operating Voltage 12 or 24 VDC and FWR unfiltered Operating Voltage Range 12 V 9 to 17.5 VDC Operating Voltage Range 24 V 17 to 33 VDC Maximum Load on Loop 3 Amps zone MODELS AND CURRENT DRAW Module CSFM 7300 1209 179 FM Approved MEA Approved UL ULC Dual listed 464 P N P N Current mA Current mA Current mA S 10th Street P O Box 610 Blue Springs Missouri 64013 0610 U S A 816 229 3405 816 229 4615 www fike com No P 1.49.01 1 Silenced Over Two Wire Circuit Any mix of Horn Strobes or Strobe only devices is acceptable Horn control connects to interruptible power source 3 Coding of 20 080 Multi Alert and 02 4999 C Sounders Strobes must be powered from non coded supply AND ENGINEERING SPECIFICATIONS Circuit Module shall be a System Sensor Sync Model listed to UL464 and shall be for fire protective service The module shall synchronize Fike strobes at 1 Hz and horns at temporal 3 Also the shall be capable of silencing the horns on horn strobe models while operating the strobes over a single pair of The module shall be capable of mounting to a 41 11 16 41 11 16 21 1 8 back box and shall control two Style Y B or one Style Z class A circuit The module shall be capable of multiple zone synchronization by connecting modules together via a slave in slave out arrangement and re synchronizing each other along the chain Note The shall not operate on a coded power supply Fike Corporation All Rights Reserved No P 1.49.01 1 August 2005 Specifications are subject to change without notice
