Fike P 1 83 01 Intelligent Graphic Annunciators

INTELLIGENT GRAPHIC ANNUNCIATORS Intelligent Graphic Annunciators are designed to be used with Fike control panels such as the Cheetah Cheetah Xi and CyberCat These annunciators provide a graphic display of the protected area L E D to indicate the location of smoke detectors or other intelligent L E D can be individually programmed to illuminate for selected addresses or zones for certain states such as alarm or trouble annunciator panels combine custom design with rugged construction display window is constructed of plexiglass over lexan and mounted in steel door The backbox is constructed of steel and houses all modules for a custom designed panel There are currently six basic sizes of available each capable of being flush or surface mounted graphic annunciators can be ordered in the either gray or black lexan comes in white with black text Optional background colors are available is 14 x 14 with a viewing window of 10 X 10 and accepts up to 64 L E D or annunciation points is 24 x 24 with a viewing window of 20 X 20 and accepts up to 384 L E D or annunciation points is 36 x 24 with viewing window of 32 X 20 and accepts up to 512 L E D or annunciation points is 24 x 36 with a viewing window of 20 X 32 and accepts up to 512 L E D or annunciation points is 36 x 30 with a viewing window of 32 X 26 and accepts up to 640 L E D or annunciation points is 30 x 36 with viewing window of 26 X 32 and accepts up to 640 L E D or annunciation points Other custom sizes are available X Black B or Gray G The number of L E D can vary depending on the graphical layout Please contact Fike to determine the maximum for your customized application Boards Graphic Micro Controller Card up to 256 L E D compatible with Cheetah CyberCat or Cheetah Xi systems Up to 4 total can be installed per enclosure Switch Card Provides switches for lamp test silence etc L E D Driver Card 1 for use of up to the first 128 L E D connected to the micro control card L E D Driver Card 2 for use of up to the second 128 L E D connected to the micro control card Assemblies Cable Assembly 24 Micro Driver Cable Assembly 48 Micro Driver Cable Assembly 24 Micro Switch Cable Assembly 10 Micro Switch switch for system reset silence graphic lamp test or system acknowledge are completely configurable through C Linx software Design to accommodate individual floor plans Basic Sizes available in black and gray or Flush Mounting with option trim ring Hinged Door Assembly With Keyed Lock Multi Color Background Available Modular circuit board design for expandability L E D Colors Amber Red Green Yellow Installation S 10th Street P O Box 610 Blue Springs Missouri 64013 0610 U S A 816 229 3405 816 229 4615 www fike com No P 1.83.01 INFORMATION Door Assemblies Annunciator 14 x 14 w 10 x 10 viewing window Annunciator 24 x 24 w 20 x 20 viewing window Annunciator 36 x 24 w 32 x 20 viewing window Annunciator 24 x 36 w 20 x 32 viewing window Annunciator 36 x 30 w 32 x 26 viewing window Annunciator 30 x 36 w 26 x 32 viewing window Door Annunciator Door 14 x 14 w 10 x 10 viewing window Annunciator Door 24 x 24 w 20 x 20 viewing window Annunciator Door 36 x 24 w 32 x 20 viewing window Annunciator Door 24 x 36 w 20 x 32 viewing window Annunciator Door 36 x 30 w 32 x 26 viewing window Annunciator Door 30 x 36 w 26 x 32 viewing window 14 x 14 for P N 10 121 X 24 x 24 for P N 10 122 X 36 x 24 for P N 10 123H X 24 x 36 for P N 10 123V X 36 x 30 for P N 10 124H X 30 x 36 for P N 10 124V X Micro Controller Card Card Driver Card 1 Driver Card 2 Assembly Micro Driver 24 Assembly Micro Driver 48 Assembly Micro Switch 24 Assembly Micro Micro 10 Ring for 14 x 14 Ring for 24 x 24 Ring for 36 x 24 Ring for 36 x 30 LED LED LED LED P N X Black B or Gray G Complete door assemblies includes one micro card one driver card one switch card and appropriate cables and L E D must be ordered separately Fike Corporation All Rights Reserved No P 1.83.01 January 2006 Specifications are subject to change without notice
