FN 4127 IO 16 CHANNEL INPUT OUTPUT BOARD BUS DEVICE Voltage Comms Bus Current per input per output per bank of outputs per I O board 1A max Distance from Capacity VDC Nominal total per I O board each as input or output to 32 expansion boards max max within overall limits max for banks 1 8 9 10 two wire ft depends on method size used for input power AWG max LED for communication status L x 2.4 W FireNET FN 4127 IO is a 16 channel Input Output that provides powerful input output expansion to the FireNET system allowing up to thirty two I O to be connected to each FireNET panel within the network Every I O board connected to any panel available to the entire network which allows for network input output mapping Typical uses include graphical map displays annunciators tabular LED zone display input output logic to from the fire system secondary use I O board points cannot be used for fire initiation inputs or notification outputs such as control burglar CCTV intercom voice or other 3rd systems Each channel can be configured to produce variety of input actions or respond to a variety of output or logic All channels can trigger or react from wide cause and effect logic depending on their The flexibility of these boards is further by the fact that each of the channels is as either an input or an output Connection be achieved through a simple two wire RS485 protocol and two wire power input I O can be mounted locally in the control panel or on a bus up to 4,000ft from the panel when the FN ACC accessory enclosure FEATURES channels of input output points I O boards per FireNET panel 512 channels of points channel configurable as input or output point are opto isolated non supervised pulldown triggered by contact from input source Outputs are open collector transistor pulldown 100mA max each that provide voltage 4 wire connection to control panel 2 for 2 for data inputs outputs can be assigned to global any event category and used in network Cause Effect logic Can be mounted locally within control panel or remotely via FN ACC accessory up to 4000ft from the panel I O board has a unique address 1 32 set via switch on the I O Comms Bus are for secondary use not for fire initiation inputs or notification outputs LED are provided for communication status LISTINGS 864 Category UOJZ CNN Signal System Control Sub Assembly S8255 Vol 1 Sec 2 compliant 7165 0410 159 subject to change without notice America Corporation Village Drive Suite 100 Buena Park CA 90621 2268 714 522 2246 Fax 714 522 2268 Support 800 845 6692 or technicalsupport hochiki com latest revision at www hochiki com
