Kidde K85001-0613 -- Intelligent Duct Smoke Detector

Intelligent Duct Detector Kidde FX PDD Duct Smoke Detector is designed for easy and represents the perfect balance of practical design advanced technology FX PDD features a unique design that speeds installation and maintenance Removable dust filters conformally coated boards and optional water resistant gaskets keep con away from components ensuring years of trouble free When cleaning is required the assemblies come apart and snap back together in seconds duct smoke detector primary purpose is to provide early of an impending fire and shut down the HVAC unit in to prevent smoke from circulating throughout the building duct smoke detector is designed for use in duct applications temperatures can exceed standard detector capabilities Duct detectors have specific limitations Duct detec are not a substitute for an open area smoke detector Duct are not a substitute for early warning detection or a for a building regular fire detection system Smoke are not designed to detect toxic gases which can up to hazardous levels in some fires These devices will not without electrical power As fires frequently cause power Kidde suggests you discuss further safeguards with local fire protection specialist Features Less than 2 deep for easy installation and applications where is tight 32 to 120 0 to 50 operating range with 100 ft min to ft min air velocity rating assures reliability under harsh conditions Status LEDs remain visible through clear assembly cover Cover monitor switch for added security Standard sampling tube spacing for easy drop in migration other detectors Sampling tube can be installed with or without the cover in and can be rotated in 45 degree increments to ensure alignment with duct airflow 15.2 to 19.95 Vdc operation Magnet activated test switch One Form C auxiliary alarm relay for controlling ancillary equip e g HVAC controls No special tools required for easy access to field connections Environmental compensation with differential sensing for reli stable and drift free sensitivity Wide 0.79 to 2.46 obscuration ft smoke sensitivity Identification of dirty or defective detectors 1 of 4 D A T A S H E E T K85001 0613 to be used for installation purposes Issue 1.1 Catalog u Intelligent Initiating Devices04 05 20Technology that saves livesROTARY ADDRESSINGfirealarmresources com relay smoke premises FX PDD duct detec is ideally suited to duct detection applica where early indication combustion is required the confined space ventilation ductwork primary purpose is to early warning of an fire and to pre smoke from circulating the building is typically used to detect smoke in the supply side of the HVAC but can provide supervision of the return side as well smoke relay detectors continually sample air flow in the HVAC duct and an alarm condition whenever smoke is detected An alarm activated when the quantity percent obscuration of combustion in that air sample exceeds the detector sensitivity set Intelligence all FX Series intelligent devices the FX PDD detector fea rotary addressing and issues a dirty sensor warning when reaches its preset limit The dirty sensor warning indicates the is operating within its specified limits but is in need of ser When the detector ability to compensate for environmen changes has reached its limit the duct smoke detector signals trouble condition FX PDD also uses differential sensing to prevent gradual changes from triggering unwanted alarms A rapid in environmental conditions such as smoke from a fire the detector to signal an alarm state but dust and debris over time does not change alarm sensitivity FX PDD detector contains a microprocessor that performs self diagnostics and stores the results in nonvola memory Stored results include details such as hours of opera last maintenance date and number of alarms and troubles information can be retrieved and reviewed when desired Configuration detector assembly cover provides easy access to the smoke its wiring connections sample and exhaust tubes and the chamber itself enters the detector sensing chamber through a sampling ordered separately that extends into the duct and is di back into the ventilation system through an exhaust tube The difference in air pressure between the two tubes the sampled air through the sensing chamber When a suf amount of smoke is detected in the sensing chamber the initiates an alarm sampling tube may be installed from either the duct side of assembly or from inside the sensor compartment as preferred the installer The exhaust tube must be installed from the duct Sampling tubes may be rotated in 45 degree increments so air holes can be aligned to allow the unit to be mounted at any angle relative to the air flow installations where the duct smoke detector controls and indica are hidden from view a remote test station or an LED indicator be connected to the detector to provide these functions 2 of 4 Test Stations Labor saving Remote Test Reset stations provide testing from the convenience of a remote Tests can be performed quickly and safely without having to climb to the roof Magnetically and key operated one gang models are FX PDD detectors are also compatible R LED remote alarm LED velocity in the duct as low as 100 ft min maintains adequate flow into the sensor smoke chamber through air holes in the sampling tube and discharges through the exhaust tube Air tubes must be installed with the inlet holes facing the air Sampling tubes may be rotated in 45 degree increments that air holes can be aligned to allow the unit to be mounted in any angle relative to the airflow sensors are engineered to operate optimally under the environmental conditions frequently found in HVAC duc Nonetheless before installing the detector test the duct velocity temperature and humidity to verify that it is within the range of the detector Consult the FX PDD installation for details station specifications Test Reset Stations provide alarm test trouble indication reset capability from a remote location They include a one plate momentary SPST switch red alarm LED and termi block Magnetically operated models TRM or key operated TRK are available electrical indicators type size per wire requirements circuit ratings ratings SD ratings SD environment temperature listings American 1 gang box Standard 4 in box 1 1 2 inches deep with 1 gang red lens to 22 AWG Ohms max controller specifications 3 Vdc max Current 30 mA max 125 Vdc max Current 4 A max Set the module address as follows Make all wiring connections as shown in 200 Vdc max Current 0.5 A max a screwdriver to adjust the two rotary switches on front of the module Set the TENS rotary switch 0 12 for the 10s and 100s digit and the ONES switch for the 0 through 9 digit For example address 21 set TENS rotary switch to 2 and set ONES rotary switch to 1 to 120 0 to 50 93 RH noncondensing to 140 20 to 60 ULC CSFM to specifications for available address detector address Addressing a screwdriver to adjust the two rotary on the front of the module Set the rotary switch 0 through 12 for the 10s 100s digit and the ONES rotary switch the 0 through 9 digit screwdriver here 6 4 5 9 Settings Determins the operation of the detector Set jumper JP3 to appropriate position Refer to operation Verify the air pressure differential value falls within the operating range of the detector in with procedures specified in and testing Alarm Factory Default Configures the detector for alarm operation After
