Honeywell IPGSM-4GC IP Internet & GSM Dual Path Fire Communicator

File Preview
File Preview
Click below to download for free

Text Preview

Fire Alarm Communicator Internet GSM Dual Path Fire Communicator IPGSM 4GC is a fire alarm communicator that offers contact ID reporting with Fire Alarm Control Panel FACP that has a built in dialer This easy to install dual communicator connects directly to the primary and secondary communication of a fire panel Digital Alarm Communicator Transmitter DACT It offers three reporting paths which include Cellular only IP only or IP primary cellular In the event of an off normal condition the fire panel sends contact ID information to the IPGSM 4GC communicator panel The IPGSM 4GC reformats the data into highly encrypted Ethernet packets for transmission to Alarm Net receiver via customer provided Internet Intranet connection or the network communication methods are critical in the marketplace due to VoIP over IP migration from POTS Plain Old Telephone Service and growth of radio networks The IPGSM 4GC exclusive dual path communications combines Internet service with GSM for added reliability and an extra level of All signals from the IPGSM 4GC communicator panel are delivered to AlarmNet Network Control Center which routes the information to the central station The state of the art AlarmNet network control center is redundant and monitored 24 7 AlarmNet has the ability to route messages AlarmNet i and 800 PLUS services providing true redundancy and multi path delivery IPGSM 4GC is designed to operate over the most common GSM platforms 3G and HSPA Its multi GSM platform technology automatically chooses best available cellular signal in the area based on signal strength and seamlessly to maintain critical life safety communication BENEFITS Base network Built In Power Supply QOS Quality of Service Saves the cost of two phone lines secondary ports Dual path Operates over the Can to station using or cellular Requires no change to existing Fire Alarm Panel The connects to the primary HSPA 4G HSDPA 3G EDGE GPRS 2G Works over any type of provided 10 100 LAN or DSL modem or modem Data transmits over contact ID but is secured the industry encryption AES 256 bit On board circuit design back battery Includes power and supervision Diagnostic LEDs strength and indicators Supports both dynamic Reliable connection IP or Public and Static IP GSM connection every day via conveys vital including message was signal and message used 7720P Hand held for easy Capabilities IPGSM 4GC is compatible with specific fire panels use the Contact ID communications format as in the SIA DC 05 standard An additional is required HFS 659EN when installing the See the product installation document details AlarmNet has been the nationwide leader alarm communications technology since 1986 A alternative for the transmission of alarm our radio network provides extensive coverage the United States and Canada AlarmNet Network center processes signals from powerful servers multiple locations equipped with 24 7 support The AlarmNet network consist redundant hardware servers hot back up databases generators with battery back up at all locations to continuity of service Signals from Alarm Net transmitted to the central station receivers using communications paths consisting of the radio network or toll free POTS service Requirements COMPLIANCE IPGSM 4GC must be mounted in the same room within 20 feet of the fire panel The wiring must routed through conduit IPGSM 4GC and all equipment used for the IP such as the router hub modem etc be listed must be powered from an un branch circuit and be provided with standby power IPGSM 4GC must use the 7AH battery not to provide 24 hour backup capability When connecting to a fire panel a line fault monitor Model HFS must be installed to monitor and report Telco troubles per the requirement an event occurs the Fire Alarm Control Panel off hook to dial the central station The IPGSM Dialer Capture Module detects the off hook and provides the fire panel with a dial tone the fire panel detects the dial tone it begins the central station After the dialing is the Dialer Capture Module returns a to the fire panel The fire panel then sends contact ID reports to the Dialer Capture Module in turn sends a kiss off after the report is received from the fire panel The Dialer Module sends the contact ID reports to the communications module When all the reports sent the fire panel goes on hook The iGSM module then transmits the messages the central station either over the GSM network or Internet primary to Program IPGSM 4GC communicator can be pre using the 7720P programmer to enter all information This is saved to the communicator panel memory When the communicator is installed at the site and to the Internet Intranet it registers itself the AlarmNet receiver This eliminates the need for PC at the remote site for programming most installations the only required parameters Primary City ID two digits obtained from your station Primary Central Station ID two digits obtained from monitoring station Primary Subscriber ID four digits obtained from monitoring station Communication Module MAC ID and MAC CRC located on outside of box and inside of the of these parameters are assigned by the monitoring Some assembly is required See Installation and Setup Guide for full details Technical Specifications 1451 UL9 120 VAC 60 Hz 850mA 18VDC 72 VA 12 V 7.0 AH lead acid battery not supplied charging current minimum 1 Amp discharge current standby 230mA active cabinet holds one 7.0 AH battery 14.875 H x 12.75 W x 3.0 D 37.8 cm H x cm W x 7.6 cm D Red 5.3 lbs 6.94 kg 15.625 H x 13.79 W x 9.25 D 39.7 cm H x cm W x 23.9 cm D AND HUMIDITY RANGES system meets NFPA requirements for operation at 0 120 and at a relative humidity 93 2 RH condensing at 32 2 90 3 However the life of the system standby batteries and the components may be adversely affected by temperature ranges and humidity Therefore it is that this system and its peripherals be in an environment with a normal room of 15 27 80 LINE INFORMATION For Canada only Internet and Digital Fire Alarm Communicator Panel Includes red with key wall outlet box Dialer Capture Module Communications Module antenna mounting PowerBoost1 power supply LED display board manual required screws cables etc Telco line fault monitor and AlarmNet are trademarks of International Inc document is not intended be used for installation We try to keep our information up to and accurate We cannot all specific applications anticipate all requirements specifications are subject to without notice 3db gain external remote antenna 50 ft antenna cable low loss 25 ft antenna cable low loss SNA to N Adapter IPGSM 4GC hand held programmer Plug in transformer box for IPGSM Battery 12 Volts 7 AH sealed LISTINGS AND APPROVALS listings and approvals below apply to the basic communicator panel In some cases certain may not be listed by certain approval agencies listing may be in process factory for latest listing status Listed S789 more information more about Honeywell IPGSM 4GC and other available by visiting www honeywe
