Notifier 7100X(A), 8100(A), 9400X(A) Conventional FAASTTM Series Detectors

7100X A 8100 A FAAST Series Detectors FAAST Series aspirating smoke detectors deliver accurate very early warning fire detection early warning detection and standard Fire Detection that meets the needs a variety of environments including mission critical facilities data centers where downtime from smoke or fires can be costly ability to configure FAAST for standard fire detection allows to be used in harsh environments where standard spot may be subject to nuisance alarm conditions As can be easily tested via a test port within the pipe net it can simplify the testing associated with standard detec Conventional FAAST Series detectors combine dual optical smoke detection blue LED and infrared laser advanced algorithms to detect a wide range of fires while enhanced immunity to nuisance particulates The enables the detectors to accurately detect incipi fire conditions as early as 30 to 60 minutes before a fire starts models are available for use in different size applica The series consists of FAAST XS FAAST XM and XT with specific model numbers of 7100X A and 9400X A The three models can provide stan detection coverage to protect the following areas 7100X A FAAST XS Up to 5,000 sq ft 464 sq m 8100 A FAAST XM Up to 8,000 sq ft 743 sq m one pipe one pipe 9400X A FAAST XT Up 28,800 sq ft 2601 sq m one to four pipes FAAST provides Form C relays that connect to points on any FACP The detector communicates alarm urgent and minor faults and isolate inputs via the To enable a full detection strategy FAAST combines its communications capabilities with an extensive of customizable settings Up to five alarm levels can be for latching or non latching relays To accommo specific codes or environments alarm delays can be set between 0 to 60 seconds FAAST series detectors offer selectable sensitiv modes In Acclimate mode the detector automatically itself to current environmental conditions to reduce nui alarms Day Night Weekend mode enables technicians preset alarm thresholds based on routine changes in the or additional monitoring is supported in several dif ways including Serial or TCP Modbus Ethernet over a or a direct connection or via onboard USB When con to a LAN FAAST series devices email server can pro email event notification to appropriate personnel is intuitive design configuration and monitoring soft used for all FAAST series devices The all in one pro can be used to create a pipe network tailored to meet specific requirements configure a FAAST device and an installed device including live trending and read of historic reports Smoke Detector FAAST Series Detectors Detection as precise as 0.00029 ft obscuration Multiple alarm levels provide application flexibility five on XM and FAAST XT three on FAAST XS Acclimate mode the detector automatically adjusts to current environmental conditions to reduce nui alarms Day Night Weekend mode enables techni to preset alarm thresholds based on routine changes the environment A Conventional FAAST series detector self adapt to its environment in 24 hours All devices provide ultrasonic sensing for pipe and chamber measurements FAAST XM offers additional elec sensing Advanced detection algorithms reject common nuisance Patented particle separator and field replaceable filter contaminants from the system system layout configuration and monitoring pro by PipeIQ software Comprehensive simple and intuitive display has real time information at the device including alarm levels levels air flow power and a wide range of faults quickly identify the problem for prompt correction The onboard Ethernet interface enables monitoring from compatible Internet browser smart phone or mobile with VPN capability Detector can be configured to status updates to appropriate personnel TCP and serial Modbus for easy integration with Building Systems Fault indicators exhibit a broad spectrum of events Unique air flow pendulum graph verifies pipe network func Particulate graph displays subtle environmental changes for problem indications Approved for use in Class I Division 2 Groups A B C and Hazardous Locations FAAST XM FAAST XT only User configurable 3 speed fan allowing for maximum cov area or minimizing current consumption 7100X A 9400X A only Detector trouble reporting at panel 07 13 2015 Page 1 of 4 activation of the event relays on the Conventional series detectors Shipping Weight 11.6 lbs 5.26 kg includes packing Coverage 28,800 sq ft 2,676 sq m through one to four Avg Operating Current Fan High 465mA 11.2W Fan 340mA 8.2W Fan Low 220mA 5.3W Alarm Fan High 493mA 11.85W Fan Med 368mA Fan Low 248mA 6W Relays 8 Form C 3 A programmable latching or non Maximum Single Pipe Length 400 ft 123 m with other pipes disabled All designs must be verified within software Total Pipe Length 1050 ft 320 m All designs must be within PipeIQ software Size 13.3 inches 33.8 cm tall x 13.1 inches 33.3 cm x 7.5 inches 19.1 cm Shipping Weight 11.8 lbs 5.4 kg includes packing for All Conventional Series Detectors SPECIFICATIONS Supply Voltage 18 30 VDC provided by a UL 864 UL 1481 listed power supply Reset Time External monitor must be pulled low for minimum of 100 ms Reset 1 sec Contact Ratings 3.0 A 30 VDC 0.5 A 125 VAC RATINGS Temperature 32 0 to 100 38 Air Temperature 4 20 to 140 60 Range 10 to 95 non condensing Rating IP30 Movement 0 4,000 ft min 0 1,219 m min Range 0.00029 ft obs 6.25 ft obs SPECIFICATIONS Network Ethernet monitoring 6 E mail alerts Modbus TCP Access Cable entry holes on top and bottom of unit 1 2.54 cm Gauge 12 AWG 2.05 mm max to 24 AWG 0.5 mm min Outside Pipe Diameter 1.050 inches IPS 25 mm Pipe Diameter 0.591 to 0.827 inches 15 21 mm Log 18,000 events stored for Specific Models Coverage Up to 5,000 sq ft 464 sq m through one pipe Avg Operating Current Fan High 200mA 4.8W Fan 151mA 3.7W Fan Low 120mA 2.1W Alarm Fan High 230mA 5.6W Fan Med 172mA 4.2W Low 142mA 3.5W Relays 5 Form C 3 A programmable latching or non Maximum Single Pipe Length 180 ft 54.8 m All must be verified within PipeIQ software Total Pipe Length 225 ft 68.6 m All designs must be within PipeIQ software Size 11.0 in 27.9 cm tall x 9.0 inches 22.9 cm wide x inches 15.9 cm deep Shipping Weight 8.8 lbs 3.99 kg includes packaging Coverage 8,000 sq ft 743 sq m through one pipe Avg Operating Current 415 mA 24 VDC Alarm 465 mA All relays active all alarm levels dis Voltage 24 VDC Relays 8 Form C 3 A programmable latching or non Maximum Single Pipe Length 262 ft 80 m All designs be verified within PipeIQ software Total Pipe Length 333 ft 101.5 m All designs must be within PipeIQ software Size 13.25 inches 33.7 cm tall x 913.0 inches 33 cm x 5.0 inches 12.7 cm deep 2 of 4 DN 60791 D 07 13 2015 Interface Display Up to five alarm levels 7100X A Three alarm levels Alert Fire 1 Fire 2 8100 A 9400X A Five alarm levels Alert Action 1 2 Fire 1 Fire 2 Ten particulate levels 7100X A Ten single
