9400X FAAST XT Fire Alarm Aspiration Technology FAAST XT 9400X adds to the FAAST line of aspirating detectors providing a four pipe solution that can protect to 28,800 sq ft 2,676 sq m in standard coverage applica FAAST XT conventional aspirating smoke detector com dual source blue LED and infrared laser optical smoke with advanced algorithms to detect a wide range of while maintaining enhanced immunity to nuisance partic enables the FAAST XT to accurately detect incipi fire conditions as early as 30 to 60 minutes before a fire starts for Early Warning Fire Detection and Very Early Fire Detection For initial system creation the software guides users through pipe layout The soft also provides intuitive control over system configuration ongoing system monitoring An installed device can be through its integral display from a computer con to the device or remotely through a computer browser mobile device when the detector is connected to a network by Modbus TCP protocol over Ethernet When Internet con the FAAST XT can also e mail status updates to personnel The detector can communicate alarm urgent and minor faults and isolate inputs via eight C relays To enable a full detection strategy the FAAST combines its advanced communications capabilities with extensive range of customizable settings The detector pro five alarm levels that can be programmed for latching or relays To accommodate specific codes or envi alarm delays can be set anywhere between 0 to 60 The FAAST XT also supports three sensitivity In Acclimate mode the detector automatically itself to current environmental conditions to reduce nui alarms Day Night Weekend mode enables technicians preset alarm thresholds based on routine changes in the Detection as precise as 0.00046 ft obscuration Five alarm levels and two sensitivity modes provide applica flexibility Dual flow detection including both ultrasonic and electronic for pipe and chamber air flow measurement A single device protects up to 28,800 square feet User configurable 3 speed fan allowing for maximum cov area or minimizing current consumption Advanced detection algorithms reject common nuisance Patented particle separator and field replaceable filter contaminants from the system PipeIQ software provides intuitive system layout configu and monitoring all in one package Using the onboard Ethernet interface you can monitor the from any Internet browser smart phone or mobile with VPN capability You can also configure the to e mail status updates to appropriate personnel Monitoring and configuration can also be accomplished Modbus TCP protocol over Ethernet Fault indicators exhibit a broad spectrum of events Smoke Detectors Unique air flow pendulum graph verifies pipe network func Particulate graph displays subtle environmental changes for problem indications 5 programmable alarm levels for latching or non latching as as a 0 to 60 second delay to best accommodate local or environments At startup the FAAST XT self adapts to its environment in 24 hours not weeks The exclusive Acclimate mode adjusts within your specified parameters to nuisance alarms and adjust to current conditions Comprehensive simple and intuitive multi lingual LCD dis has real time quick read information at the device five alarm levels ten particulate levels air flow and a wide range of faults to quickly identify the for prompt correction SPECIFICATIONS Supply Voltage 18 30 VDC Reset Time External monitor must be pulled low for minimum of 100 ms Reset 1 sec Operating Current Fan High 465mA 11.2W Fan Med 340mA 8.2W Fan Low 220mA 5.3W Fan High 493mA 11.85W Fan Med 368mA 8.85W Low 248mA 6W Contact Ratings 3.0 A 30 VDC 0.5 A 125 VAC 11 11 14 Page 1 of 2 RATINGS Temperature 32 0 to 100 38 Air Temperature 4 20 to 140 60 Range 10 to 95 non condensing Rating IP30 Area 28,000 sq ft 2,676 sq m Movement 0 4,000 ft min 0 1,219 m min SPECIFICATIONS 13.3 inches 33.8 cm 13.1 inches 33.3 cm 7.5 inches 19.1 cm 8 Form C 3 AMP programmable latching or non Network Ethernet monitoring 6 E mail alerts Modbus TCP Access 4 1 inch 2.54 cm cable entry holes on top bottom of unit Gauge 12 AWG 2.05 mm max to 24 AWG 0.5 mm Single Pipe Length 400 ft 123 m Other three disabled Pipe Length 1050 ft 320 m All designs must be veri within PipeIQ software Outside Pipe Diameter 1.050 inches IPS 25 mm Pipe Diameter 0.591 to 0.827 inches 15 21 mm Range 0.00046 ft obs 6.25 ft obs 0.0015 to 20.5 Obs m Log 18,000 events stored Weight 11.8 lbs 5.4kg includes packing material Interface Display Five alarm levels Alert Action 1 Action 2 Fire 1 and 2 Ten particulate levels Ten bi color flow Fault graph Listings and Approvals listings and approvals below apply to Intelligent FAAST components In some cases certain modules or applica may not be listed by certain approval agencies or listing be in process Consult factory for latest listing status UL Listed S911 ULC Listed S911 FM approved Line Information FAAST XT Conventional aspirating smoke detector Replacement Air Filter CPVC Pipe 210 feet total Coupling 15 each 45 Elbow 10 each 90 Elbow 20 each End Cap 25 each Tee 15 each Union 10 each Pipe Label 100 each Sampling Point Labels 100 each Sampling Point Kit 10 sets Power Supply 12 24VDC 2.4 A DC software is available for download at no charge at Interface Display by Honeywell International Inc All rights reserved Unauthorized use this document is strictly prohibited document is not intended to be used for installation purposes We try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice more information contact Notifier Phone 203 484 7161 FAX 203 484 7118 2 of 2 DN 60847 A 11 11 14
