Notifier BB-17 Battery Box Product Installation Drawing

File Preview
File Preview
Click below to download for free

File Data

Name notifier-bb-17-battery-box-product-installation-drawing-2987543016.pdf
Type PDF
Size 998.79 KB

Text Preview

Fire Alarm Control Panel minimum Battery Box Battery Box Installation Drawing 15535 Rev B 15736 B ECN 93 345 3 7 94 BB 17 Battery Box may be used to house to two 17AH batteries It mounts directly the FACP cabinet Knockouts are pro on the top surface of the battery box 1 1 4 Description Battery Box Cabinet Battery Box Cover Screws Remove knockouts in the bottom of the cabinet and the top of the BB 17 Align knockouts in FACP and BB 17 the BB 17 to wall using 1 4 cid 148 diam holes in back of cabinet Run conduit between the BB 17 cabinet the FACP cabinet Make sure there is least 1 2 cid 148 of clearance between the BB and the FACP see illustration at left Run battery cable through conduit from into battery box Connect cable to Secure the BB 17 cover to cabinet using self threading screws Clintonville Road CT 06472 484 7161 203 484 7118
