Notifier Monitor Modules with FlashScan Data Sheet

FMM 1 A FMM 101 A FDM 1 A Modules with FlashScan different monitor modules are available for Notifier control panels for a variety of applications Monitor supervise a circuit of dry contact input devices as conventional heat detectors and pull stations or and power a circuit of two wire smoke detectors is a standard sized module typically mounts to a 10.16 cm square box that supervises either a Style D A or Style B Class B circuit of dry contact input is a miniature monitor module a mere 1.3 cm H x 2.75 6.985 cm W x 0.65 1.651 cm D that a Style B Class B circuit of dry contact input Its compact design allows the FMM 101 A to be in a single gang box behind the device it monitors is a standard sized module that monitors and compatible two wire 24 volt smoke detectors on Style D Class A or Style B Class B circuit is a standard sized dual monitor module that mon and supervises two independent two wire Style B Class dry contact initiating device circuits IDCs at two separate addresses in intelligent two wire systems U S Patent 5,539,389 is a communication developed by NOTIFIER that greatly increases the of communication between analog intelligent devices devices communicate in a grouped fashion If one the devices within the group has new information the CPU stops the group poll and concentrates on single The net effect is response speed greater than five that of other communication protocols Monitor Module Built in type identification automatically identifies this as a monitor module to the control panel Powered directly by two wire SLC loop No additional required High noise EMF RFI immunity SEMS screws with clamping plates for ease of wiring Direct dial entry of address 01 159 on FlashScan loops 99 on CLIP loops LED flashes green during normal operation programma option and latches on steady red to indicate alarm FMM 1 A Monitor Module is intended for use in intelli two wire systems where the individual address of each is selected using the built in rotary switches It pro either a two wire or four wire fault tolerant Initiating Circuit IDC for normally open contact fire alarm and devices The module has a panel controlled LED The FMM 1 A can be used to replace MMX 1 A in existing systems APPLICATIONS to monitor a zone of four wire smoke detectors manual alarm pull stations waterflow devices or other normally Devices Type H dry contact alarm activation devices May also be used monitor normally open supervisory devices with special indication at the control panel Monitored circuit be wired as an NFPA Style B Class B or Style D Class Initiating Device Circuit A 47K Ohm End of Line Resistor terminates the Style B circuit No resistor is for supervision of the Style D circuit OPERATION FMM 1 A uses one of the available module addresses an SLC loop It responds to regular polls from the control and reports its type and the status open normal short its Initiating Device Circuit IDC A flashing LED indicates the module is in communication with the control panel LED latches steady on alarm subject to current limita on the loop SPECIFICATIONS operating voltage 15 to 32 VDC current draw 5.0 mA LED on operating current 375 LED flashing 1 com every 5 seconds 47k EOL IDC wiring resistance 1500 Ohms IDC Voltage 11 Volts resistance 47K Ohms range 32 to 120 0 to 49 range 10 to 93 noncondensing 4.5 11.43 cm high x 4 10.16 cm wide x 3.175 cm deep Mounts to a 4 10.16 cm square x 5.398 cm deep box 07 30 2015 Page 1 of 4 Mini Monitor Module Built in type identification automatically identifies this as a monitor module to the panel Powered directly by two wire SLC loop No additional required High noise EMF RFI immunity Tinned stripped leads for ease of wiring Direct dial entry of address 01 159 on FlashScan loops 99 on CLIP loops FMM 101 A Mini Monitor Module can be installed in a junction directly behind the monitored unit Its size and light weight allow it to be installed without rigid The FMM 101 A is intended for use in intelligent systems where the individual address of each mod is selected using rotary switches It provides a two wire device circuit for normally open contact fire alarm security devices The FMM 101 A can be used to MMX 101 A modules in existing systems APPLICATIONS to monitor a single device or a zone of four wire smoke manual fire alarm pull stations waterflow devices other normally open dry contact devices May also be to monitor normally open supervisory devices with spe supervisory indication at the control panel Monitored cir is wired as an NFPA Style B Class B Initiating Circuit A 47K Ohm End of Line Resistor provided the circuit OPERATION FMM 101 A uses one of the available module on an SLC loop It responds to regular polls from control panel and reports its type and the status open of its Initiating Device Circuit IDC SPECIFICATIONS operating voltage 15 to 32 VDC operating current 350 1 communication 5 seconds 47k EOL 600 Max Communicating Shorted IDC wiring resistance 1500 Ohms IDC Voltage 11 Volts IDC Current 450 resistance 47K Ohms 2 of 4 DN 6720 E 07 30 2015 range 32 to 120 0 to 49 range 10 to 93 noncondensing 1.3 3.302 cm high x 2.75 6.985 cm wide x 1.651 cm deep length 6 15.24 cm minimum Interface Module Supports compatible two wire smoke detectors Supervises IDC wiring and connection of external power High noise EMF RFI immunity SEMS screws with clamping plates for ease of wiring Direct dial entry entry of address 01 159 on FlashScan 01 99 on CLIP loops LED flashes during normal operation this is a program LED latches steady to indicate alarm on command from option panel FZM 1 A Interface Module is intended for use in intelli addressable systems where the individual address of module is selected using built in rotary switches This allows intelligent panels to interface and monitor two conventional smoke detectors It transmits the status open or alarm of one full zone of conventional back to the control panel All two wire detectors monitored must be UL compatible with the module FZM 1 A can be used to replace MMX 2 A modules in systems APPLICATIONS the FZM 1 A to monitor a zone of two wire smoke The monitored circuit may be wired as an NFPA B Class B or Style D Class A Initiating Device Cir A 3.9 K Ohm End of Line Resistor provided terminates end of the Style B or D class B or A circuit maximum loop resistance is 25 Ohms Install ELR across termi 8 and 9 for Style D application OPERATION FZM 1 A uses one of the available module addresses an SLC loop It responds to regular polls from the control and reports its type and the status open normal short its Initiating Device Circuit IDC A flashing LED indicates the module is in communication with the control panel LED latches steady on alarm subject to current limita on the loop SPECIFICATIONS operating voltage 15 to 32 VDC current draw 5.1 mA LED on IDC wiring resistance 25 Ohms operating current 270 1 communication and LED flash every 5 seconds 3.9k eol resistance 3.9K Ohms supply voltage between Terminals T10 and DC voltage 24 volts power limited Ripple voltage 0.1 Vrms maximum Current 90 mA per module maximum range 32 to 120 0 to 49 Listings and Approvals some cases certain modules may not be listed by certain agencies
