N ANN 80C 80 Character Serial LCD Indicator N ANN 80C indicator is a compact backlit 80 character LCD indicator that mimics the Fire Alarm Control Panel FACP dis It provides system status indicators for AC Power Alarm Trou Supervisory and Alarm Silenced conditions The N ANN 80C the FACP communicate over a two wire serial interface employ the ANN Bus communication format Connected devices are via two additional wires by either the host FACP or a ULC listed filtered power supply The N ANN 80C is black N ANN 80C displays English language text of system point including device type zone independent point alarm or supervisory status as well as any custom alpha labels into the control panel It includes buttons for local lamp test and sounder test A keyswitch prevents unautho operation to eight N ANN 80Cs may be connected to the ANN Bus of each Minimal programming is required which saves time during commissioning The N ANN 80C is compatible with NOTI FACPs with an ANN Bus such as the NFW 50 ULC listed meets all Canadian requirements for a fire alarm Backlit 80 character LCD display 20 characters x 4 lines Buttons for local silence lamp test and sounder test Keyswitch enables disables buttons and mechanically locks indi enclosure Keyswitch can be enabled or disabled at the FACP Enclosure supervised for tamper System status LEDs for AC Power Alarm Trouble Supervisory Alarm Silence Local sounder can be enabled or disabled at the FACP N ANN 80C connects to the ANN BUS terminal on the FACP and minimal panel programming Displays device type identifiers individual point alarm trouble zone and custom alpha labels Time and date display field Surface mount directly to wall or to single double or 4 square box Semi flush mount to single double or 4 square electrical box ANN SB80KIT for angled view mounting Can be remotely located up to 1,800 m from the panel Backlight turns off during AC loss to conserve battery power but turn back on if an alarm condition occurs May be powered by 24 VDC from the host FACP or by remote supply requires 24 VDC and Indicators AC Power Alarm Trouble Supervisory Alarm Silenced Local Silence Lamp Test Sounder Test Operating voltage range 18 VDC to 28 VDC Current consumption 24 VDC nominal filtered and non 40 mA maximum Ambient temperature 0 to 49 Relative humidity 93 2 RH non condensing at 32 13.65 cm high x 17.46 cm wide x 3.49 cm deep For use indoors in a dry location All connections are power limited and supervised ANN Bus THE DEVICES ON THE ANN BUS FROM AUXIL POWER SUPPLY ANN Bus can be powered by an auxiliary power supply when maximum number of ANN Bus devices exceeds the ANN Bus requirements See the FACP manual for more information DEVICE ADDRESSING ANN Bus device requires a unique address ID Number in to communicate with the FACP A maximum of 8 devices can connected to the FACP ANN Bus communication circuit See the manual for more information REQUIREMENTS COMMUNICATIONS CIRCUIT N ANN 80C connects to the FACP ANN Bus communications To determine the type of wire and the maximum wiring dis that can be used with FACP ANN Bus accessory modules it necessary to calculate the total worst case current draw for all on a single 4 conductor bus The total worst case current is calculated by adding the individual worst case currents for module For total worst case current draw on a single ANN Bus refer to FACP manual 3 15 2018 Page 1 of 2 REQUIREMENTS POWER CIRCUIT 14 to 18 AWG 0.75 2.08 mm2 wire for 24 VDC power circuit is All connections are power limited and supervised A maximum of eight N ANN 80C modules may be connected to circuit Options Black 80 character LCD Indicator Black surface mount backbox with angled wedge Listings and Approvals listings and approvals below apply to the N ANN 80C In some certain modules may not be listed by certain approval agen or listing may be in process Consult factory for latest listing ULC S635 Whitmore Road Ontario LZL 7Z4 document is not intended to be used for installation purposes try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice is a registered trademark of Honeywell International Inc by Honeywell International Inc All rights reserved Unauthorized of this document is strictly prohibited of Origin USA
