N ANN I O LED Driver Module N ANN I O is an LED driver module that can be used in a wide of applications including as an interface with the Fire Alarm Panel FACP to drive most customized graphic annuncia It comes in a plastic enclosure that may be mounted inside a annunciator or accessory cabinet and can drive up to 40 N ANN I O and the FACP communicate over a two wire serial employing the ANN Bus communication format An addi two wires are used for 24 volt DC power A single four con unshielded cable may be used for both power and data to eight ANN Bus devices may be connected to the ANN Bus of FACP N ANN I O connects to the ANN Bus terminal on the FACP and minimal programming Each N ANN I O module drives up to 40 LEDs Programmable to indicate activity for points or zones Compatible with the NFW 100X NFW 50X NFW2 100 NFW 50 RP 2002 SFP 5UD and SFP 10UD Can be remotely located up to 6,000 feet 1,829 m from the May be powered by 24 VDC from the host FACP or by remote supply requires 24 VDC Up to eight ANN Bus devices may be connected to the ANN Bus each FACP Maximum ANN Bus Voltage 24 VDC Maximum Current Alarm 200 mA Standby 35 mA Each LED 10mA Maximum wiring distance from FACP 6000 ft 1829 m Ambient Temperature 32 to 120 0 to 49 Relative Humidity 93 2 RH non condensing at 32 2 3 For use indoors in a dry location Connections to FACP are power limited and supervised External measurements 6.00 15.2 cm high x 7.76 19.7 cm x 1.46 3.7 cm deep Listings and Approvals listings and approvals below apply to the N ANN I O In some certain modules may not be listed by certain approval agen or listing may be in process Consult factory for latest listing UL S635 CSFM 7120 0028 0242 MEA 442 06 E Vol 2 ANN Bus THE DEVICES ON THE ANN BUS FROM AUXIL POWER SUPPLY devices can be powered by an auxiliary power supply available panel power is exceeded See FACP manual for DEVICE ADDRESSING ANN Bus device requires a unique address ID Number in to communicate with the FACP A maximum of eight devices be connected to the FACP ANN Bus communication circuit See FACP manual for more information 3 15 2018 Page 1 of 2 Clintonville Road CT 06472 document is not intended to be used for installation purposes try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice is a registered trademark of Honeywell International Inc by Honeywell International Inc All rights reserved Unauthorized of this document is strictly prohibited of Origin USA
