NBG 12 Series Conventional Manual Alarm Pull Stations NOTIFIER NBG 12 Series is a cost effective feature series of non coded manual fire alarm pull stations It designed to meet multiple applications with the installer and in mind The NBG 12 Series features a variety of mod including single and dual action versions NBG 12 Series provides an alarm initiating input signal to fire alarm control panels FACPs such as the Series and to XP Transponders Its innovative design construction and multiple mounting options make the Series simple to install maintain and operate Aesthetically pleasing highly visible design and color Attractive contoured shape and light textured finish Meets ADA 5 lb maximum pull force Meets UL 38 Standard for Manually Actuated Signaling Boxes Easily operated single or dual action model dependent designed to prevent false alarms when bumped shaken jarred PUSH IN PULL DOWN handle latches in the down position to indicate the station has been operated The word appears on top of the handle in yellow further indicating operation of the station Operation handle features white arrows showing basic opera direction for non English speaking persons Braille text included on finger hold area of operation handle across top of handle Multiple hex and key lock models available U S patented hex lock needs only a quarter turn to lock Station can be opened for inspection and maintenance with initiating an alarm Product ID label viewable by simply opening the cover label made of a durable long life material The words and are molded into the adjacent to the alarm switch located inside Four position terminal strip molded into backplate Terminal strip includes Phillips combination head captive 8 32 for easy connection to Initiating Device Circuit IDC Terminal screws backed out at factory and shipped ready to field wiring up to 12 AWG 3.1 mm Terminal numbers are molded into the backplate eliminating need for labels Switch contacts are normally open Can be surface mounted with SB 10 or SB I O or semi mounted Semi flush mount to a standard single gang or 4 10.16 cm square electrical box Backplate is large enough to overlap a single gang backbox by 1 2 1.27 cm Optional trim ring BG12TR Spanish versions FUEGO available NBG 12LSP NBG 12LPSP Designed to replace the legacy NBG 10 Series Models packaged in attractive clear plastic PVC clam Point of Purchase packages Packaging includes cutaway dust paint cover in shape of pull station I 410 Initiating Devices Cover backplate and operation handle are all molded of polycarbonate material Cover features white lettering and trim Red color matches System Sensor popular SpectrAlert horn strobe series NBG 12 manual pull stations provide a textured finger hold that includes Braille text In addition to PUSH IN and PULL text there are arrows indicating how to operate the sta provided for non English speaking people in and then pulling down on the handle activates the alarm switch Once latched in the down position word appears at the top in bright yellow with a of the handle protruding at the bottom as a visible flag the station is simple insert the key or hex model twist one quarter turn then open the station front causing the spring loaded operation handle to return to original position The alarm switch can then be reset to its non alarm position manually by hand or by closing station front cover which automatically resets the switch SPECIFICATIONS station in cm 4.121 in cm in cm in cm in cm in cm in cm in cm in cm in cm in cm in cm in cm in cm in cm SPECIFICATIONS contact ratings gold plated rating 0.25 A 30 VAC or Auxiliary contact circuit Terminals 3 4 NBG 12LA to 3.0 A 30 VAC or VDC 04 22 08 Page 1 of 2 SPECIFICATIONS Fire Alarm Stations shall be non code with a key or reset lock in order that they may be tested and so that after actual Emergency Operation they cannot be to normal except by use of a key or hex An operated shall automatically condition itself so as to be visually as activated Manual stations shall be constructed of colored LEXAN or polycarbonate equivalent with clearly operating instructions provided on the cover The word shall appear on the front of the stations in white letters inches 2.54 cm or larger Stations shall be suitable for mounting on matching backbox SB 10 or SB I O or mounting on a standard single gang double gang or 10.16 cm square electrical box and shall be installed within limits defined by the Americans with Disabilities Act ADA or national local requirements Manual Stations shall be Under Laboratories listed The words on the NBG 12LSP and NBG shall appear on the front of the station in white letters 3 4 1.905 cm high Models NBG 12LPS and NBG 12LPSP pull stations are non coded pull stations which provide a FACP with two normally alarm initiating input signals input is activated pushing in then pulling down the dual action handle A alarm input signal can be manually activated via a momen rocker switch mounted inside the unit This general alarm can only be accessed by opening the cover with the sup key lock See diagram at right Listings and Approvals listings and approvals below apply to the NBG 12 Series stations In some cases certain modules may not be listed certain approval agencies or listing may be in process Con factory for latest listing status C UL US Listed file S692 CSFM approved file 7150 0028 199 FM approved except NBG 12LPS NBG 12LPSP MEA approved file 67 02 E NBG 12 NBG 12L NBG 12LOB Lloyd Register type approved file 93 60141 E3 NBG 12 NBG 12LA NBG 12LOB NBG 12S U S Coast Guard approved files 161.002 23 3 AFP 200 with NBG 12L NBG 12S 161.002 42 1 NFS 640 with NBG 12L NBG 12S 161.002 27 3 AFP1010 with NBG 12 NBG 12L NBG 12S Patented U S Patent No D428,351 6,380,846 6,314,772 Line Information Single action pull station with pigtail connections lock Dual action pull station with SPST N O switch screw connections hex lock Dual action pull station with SPST N O switch terminal connections key lock Same as NBG 12L with English Spanish FIRE labeling Dual action pull station with pre signal option Same as NBG 12LPS with English Spanish labeling Dual action pull station with key lock outdoor listings NBG 12LO and backbox Includes SB I O backbox and sealing gasket Model will also to WP 10 weatherproof backbox in retrofit applications NBG 12LO not available separately approved backbox NBG 12LOB applications listings apply to NBG 12LOB combination Dual action pull station with key lock and annuncia contacts Surface mount backbox metal Surface mount backbox plastic Included with NBG Optional trim ring for semi flush mounting Outdoor use backbox Keys set of two Included with key lock pull stations Hex key 9 64 Included with hex lock pull stations For addressable NBG 12LX models see data sheet SpectrAlert Advance and System Sensor are registered of H
