NC 100 A Module for Series Panels NC 100 A Addressable Control Module provides NOTI FireWarden Series intelligent control panels a super Class B Style Y of Class A Style Z circuit for Appliances horns strobes etc Addressability the NC 100 A to be activated either manually or panel programming on a select zone or area of cov basis Built in type identification automatically identifies these to the control panel circuitry powered directly by two wire SLC loop NC 100 A module requires power for horns strobes LED when communicating and turns on when activated High noise immunity EMF RFI The NC 100 A may be used to switch 24 volt NAC power Wide viewing angle of LED SEMS screws with clamping plates for wiring ease Direct Decade entry of address 01 99 with FireWarden or 01 50 with the FireWarden 50 C NC 100 A is used to switch 24 VDC audible visual power The face plate is made of off white heat resistant plastic Controls include two rotary switches for direct dial entry of setting The NC 100 A is configured for a single Class B Style Y Class A Style Z Notification Appliance Circuit NC 100 A uses one of the module addresses on a SLC It responds to regular polls from the control panel and its type and status including the open normal short of its Notification Appliance Circuit NAC The LED with each poll received On command it activates its relay The NC 100 A supervises Class B Style Y or A Style Z notification or control circuits code command from the panel the NC 100 A will dis the supervision and connect the external power sup in the proper polarity across the load device The of the supervision provides a positive indication the panel that the control relay actually turned ON The power supply is always relay isolated from the com loop so that a trouble condition on the external supply will never interfere with the rest of the system switches set a unique address for each module The may be set before or after mounting The built in CODE not settable will identify the module to the con panel A1 360 operating voltage 15 to 32 VDC SLC current draw 6.5 mA LED on operating current 350 cid 2 A LED flashing supply voltage maximum 80 volts RMS or DC on external supply 2 mA maximum using internal relay resistance 47K ohms range 32 to 120 0 to 49 range 10 to 93 non condensing 4.5 11.43 cm high x 4 10.16 cm wide x 3.175 cm deep Mounts to a 4 10.16 cm square x 5.398 cm deep box Listings and Approvals some cases certain modules may not be listed by certain agencies or listing may be in process Consult fac for latest listing status FM approved UL ULC Listed file S635 CSFM approved file 7300 0028 230 MEA approved file 72 01 E Vol 2 06 17 10 Page 1 of 2 Ratings VDC VDC VDC VDC VDC VDC VAC Application VAC VAC A VAC Line Information Intelligent addressable control module Intelligent addressable control module ULC listed Optional surface mount backbox Optional control module barrier required by UL for power limited and non power limited wiring in the junction box as NC 100 A For installation instructions see document I56 2592 001 refer to the SLC Wiring Manual document 52304 The NC relay module previously on this data sheet is now on A A A A A A A A A is a registered trademark of Honeywell International Inc by Honeywell International Inc All rights reserved Unauthorized use this document is strictly prohibited document is not intended to be used for installation purposes We try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice more information contact Notifier Phone 203 484 7161 FAX 203 484 7118 in the U S A 2 of 2 dn 7000 a2 06 17 10
