Notifier NI-100(A) Data Sheet

File Preview
File Preview
Click below to download for free

File Data

Name notifier-ni-100-a-data-sheet-8072693154.pdf
Type PDF
Size 650.83 KB

Text Preview

NI 100 A Addressable Ionization for FireWarden Systems NI 100 A addressable low profile plug in ionization uses a state of the art ionization sensing chamber to open area protection and is used exclusively with FireWarden Series addressable Fire Alarm Con Panels FACPs The ionization detector is used to sense and report the measured level of such to the fire alarm control panel Since this detector is it will help emergency personnel quickly locate a during its early stages potentially saving precious rescue while also reducing property damage Two LEDs on each light to provide a local visible sensor indication LED annunciator capability is available as an optional PN RA100Z A loop Two wire loop connection Unit uses base for wiring Addressable by device Rotary decimal addressing 01 99 with FireWarden 100 01 50 with FireWarden 50 Unique single source dual chamber design to respond and dependably to a broad range of fires communications and built in type identification Sleek low profile design Built in tamper resistant feature Removable cover and insect resistant screen for simple cleaning Withstands air velocities up to 1,200 feet per minute 6.1 m without triggering a false alarm Factory preset at 1.5 nominal sensitivity for panel alarm level Visible LED when the unit is addressed communi with the fire panel and latches on in alarm Sealed against back pressure Direct surface mounting or electrical box mounting Base mounts to single gang box 3.5 8.89 cm or 4.0 cm octagonal box or 4.0 10.16 cm square electri box using a plaster ring ionization detectors in life safety applications to provide a range of fire sensing capability especially fast flaming Where smoldering fires are anticipated a photoelectric may provide faster response detectors are constructed of off white plastic NI 100 A low profile smoke detectors are designed to commer standards and offer an attractive appearance A1 300 in B210LP A Base plug in detectors use a detachable mounting base simplify installation service and maintenance base all base types on an electrical backbox which is least 1.5 3.81 cm deep For a chart of compatible junction see DN 60054 Because of the inherent supervision provided by the SLC end of line resistors are not required Wiring or are permitted for Style 4 Class B wiring NI 100 A uses one of 99 possible addresses on the or one of 50 possible addresses on the Series Signaling Line Circuit to regular polls from the system and reports its type status NI 100 A addressable ionization sensor unique unipolar responds quickly and uniformly to a broad range of conditions and can withstand wind gusts up to 1,200 6.01 m sec without sending an alarm level Because of its unipolar chamber the NI 100 A is two times more responsive than most ionization This makes it a more stable detector range 15 32 VDC peak current 300 cid 2 A 24 VDC current 6.5 mA 24 VDC latched velocity 1,200 ft min 6.1 m sec maximum 2.0 51 mm high base determines diameter B210LP A 6.1 15.5 cm diameter B501 A 4.1 10.4 cm diameter B200SR A 6.875 17.46 cm diameter B224RB A 6.2 15.748 cm diameter 01 05 2012 Page 1 of 2 Test magnet with telescoping handle Detector removal tool Allows installation and or of detector heads from bases in high ceiling applica Extension pole for XR2B Comes in three 5 foot 1.524 sections Detector removal tool without pole Black detector covers box of 10 White detector covers box of 10 3.6 oz 102 g 0 to 49 32 to 120 humidity 10 93 noncondensing and Approvals and approvals below apply to the NI 100 A detector some cases certain modules may not be listed by certain agencies or listing may be in process Consult fac for latest listing status UL Listed S1115 ULC Listed S1115 CSFM 7271 0028 0233 MEA 319 02 E Vol II Maryland State Fire Marshal permit 2173 FM approved Line Information suffix indicates ULC Listed model Addressable Same as above with ULC Listing B210LPA base detector B210LP base BASES suffix indicates ULC Listed model For details about intelligent bases and their mounting see Plug in detector base included standard U S low profile mounting base Bulk pack of B210LP package contains 10 Standard European flangeless mounting base Bulk pack of B501 package contains 10 Intelligent sounder base capable of producing output with ANSI Temporal 3 or continuous tone B501BH series bases in retrofit applications Plug in System Sensor relay base Screw termi up to 14 AWG 2.0 mm Relay type Form C Rating 2.0 30 VDC resistive 0.3 A 110 VDC inductive 1.0 A VDC inductive Plug in System Sensor isolator detector base 25 devices between isolator bases See DN 6994 Retrofit flange to convert B210LP A to match the profile or to convert older high profile bases to Bulk pack of F110 package contains 15 Replacement flange for B210LP A base Remote LED annunciator 3 32 VDC Mounts to U S single gang electrical box For use with B501 A and bases only Surface mounting kit magnet is a registered trademark of Honeywell International Inc by Honeywell International Inc All rights reserved Unauthorized use this document is strictly prohibited document is not intended to be used for installation purposes We try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice more information contact Notifier Phone 203 484 7161 FAX 203 484 7118 in the U S A 2 of 2 DN 6996 B1 01 05 2012
