NEMA Marine Enclosure PL XM Backbox Installation Drawing 50008 Rev C ECN 01 042 cabinets should be mounted to the NEMA backplate prior to mounting in the NEMA enclosure the supplied mounting hardware 10 32 for the AFP 200 cabinet or 1 4 20 for SBB X3 cabi The mounting holes labeled in the illustration below are used for mounting the AFP 200 The holes labeled are for SBB A3 backbox installations Note The PL BM mounting not shown will only mount an SSB B3 backbox mounting the plate to the NEMA enclosure use the hardware provided with the plate Refer to documentation supplied with the NEMA enclosure for complete installation instructions END UP PLATE Dress Panel PL A3 PLATE Panel 50008 Rev C 10 26 01
