NFC 50 100 E First Command First Command NFC 50 100 and NFC 50 100E are emergency voice evacuation panels for fire appli mass notification applications or both The First Com delivers 50 or 100 watts of audio power for distribution to to eight speaker circuits i e zones The NFC 50 100 E standard with a single speaker circuit and a built in 50 25V amplifier A secondary 50 watt amplifier NFC BDA can be added for single speaker circuit backup or to system capacity to two speaker circuits and an addi 50 watts of audio power An optional NFC CE6 module to the NFC 50 100 E will upgrade the system to a max of eight speaker circuit outputs All speaker output cir can be wired in either Style Y Class B or Style Z Class configuration The NFC 50 100 E has fourteen field pro messages up to 60 seconds each built in field pre and post announce tone generators and a supervised Notification Appliance Circuit NAC with 2.0 of synchronized NAC power The NFC 50 100 E three built in Form C relay contacts AC power trou and MNS active a NAC follower and 500mA special appli power A built in power supply delivers operational and an onboard battery charger supports charging up 26AH batteries NFC cabinet holds up to 18AH batteries fire protection applications the NFC 50 100 E is an slave to any UL listed FACP providing reverse polar or contact closure can be used as a stand alone unit for applications For seamless integration between fire mass notification the NFC 50 100 E can be directly acti via serial communication between the NFW2 100 NFS or NFS2 640 Activation of the NFC 50 100 E via other uses the eight on board Command Input Circuits Two of the eight CMD circuits CMD 1 CMD 2 can individually field programmed for activation by an FACP Appliance Circuit reverse polarity and all eight can activated by a contact closure In addition the NFC 50 can be activated from a building Private Branch PBX with the integral night ring feature NFC 50 100 E programming is done by using a simple programming utility accessed from any laptop For flexibility the NFC 50 100 E supports both 25V and speaker output operation By adding a 70V transformer module NFC XRM 70V or an additional 70 volt amplifier NFC BDA 25 70V the system supports volt speaker devices NFC 50 100 E can expand in order to accommodate or more complex installations To add more control and system capacity any combination of up to eight remote consoles including the NFC LOC NFC RPU NFC RM and up to eight distributed audio amplifiers the NFC 50DA E NFC 100DA E and NFC 125 can be connected on the external data bus and audio data bus to create a fully integrated command center A loaded system supports up to 1100 watts of total audio and up to 24 speaker circuit outputs Evacuation Emergency Communications System APPLICATIONS Schools Theaters Auditoriums Nursing Homes Military facilities Places of Worship Factories Office Buildings Restaurants UL Listed to UL 2572 Communication Control Units Mass Systems and UL 864 emergency voice evacu for fire Modular design for system flexibility and easy expansion Removable terminal blocks 50 watts of 25V audio power expandable to 100 watts 2 amp Notification Appliance Circuit NAC output sync or follower for System Sensor Wheelock or Gen protocols Optional 70Vtransformer available for the primary amplifier that speaker wiring continues to be supervised in alarm and when background music is playing with optional transformer installed Eight Command Input Circuits to activate messages 1 to 8 CMD1 and CMD2 are field selectable to be activated from or 24 VDC Notification Appliance Circuits reverse or contact closures CMD3 CMD8 are activated by contact closures Speaker Circuits Single Style Y Class B or Style Z Class A speaker Cir 10 23 2015 Page 1 of 6 Two Style Y Class B or Style Z Class A speaker cir with optional NFC BDA 25 70V Audio Amplifier Eight Style Y Class B or Style Z Class A speaker cir with optional NFC BDA 25 70V and NFC CE6 520Hz square wave available which can be to the NFC 50 100 to meet NFPA Low Frequency Refer to the Device Compatibility Document for listed compatible speakers NFC 50 100 E can be controlled by an FACP via the ANN EIA 485 link of the NFW2 100 and via the ACS link of the NFS 320 or NFS2 640 The NFS 320 NFS2 640 must be firmware version 20.0 or higher Certified for seismic applications when used with the appro seismic mounting kit supervised microphone Microphone time out feature which reverts back to prere message if emergency page exceeds the pro time 14 recorded messages Field selectable message and custom message recording using the local microphone a USB port or an audio input External Audio Input can be used for background music Up to 60 second message duration for all messages tone generators field selectable for multiple tone Powered by integral AC power supply or batteries during fail Programmable delay of immediate 2 hours or 6 hours of AC Loss Piezo sounder for local trouble 100 event history log Three Form C relays AC Power Loss Relay TB1 System Trouble Relay TB2 MNS Active TB3 500mA 0.5A Special Application auxiliary power output addressable modules when interfaced with compatible FACPs and End of Line power supervision System Status LEDs Refer to and Indicators in manual LS10001 001NF E Dress Panel Optional TR CE B semi flush trim ring Any combination of up to eight 8 external remote con Optional NFC RM Remote Microphone includes cabinet DN 60778 DN 60775 Optional NFC RPU Remote Page Unit includes cabinet Optional NFC LOC Local operator console includes cab See DN 60777 Any combination of up to eight 8 distributed audio amplifi Optional NFC 50DA E distributed amplifier 50 watts See Optional NFC 125DA E distributed amplifier 125 watts DN 60776 Optional NFC 50 100 distributed amplifier with backup 50 100 watts See DN 60776 2 of 6 DN 60772 A6 10 23 2015 Internal Expansion Modules Circuit Expander Module provides connections for to six Style Z Class A or Style Y Class B speaker cir Circuits are configured through the web based program utility 25V 50 watt audio amplifier module Adding a speaker circuit increases the total NFC 50 100 power to 100 watts or can also be used as a backup amplifier 70V 50 watt audio amplifier module Adding a speaker circuit increases the total NFC 50 100 power to 100 watts or can also be used as a backup amplifier 70V Transformer Conversion Module Con the NFC 50 100 E primary amplifier to a 70V output transformer mounts directly to the NFC 50 100 E main board by two metal brackets and Indicators BUTTON CONTROLS All Call MNS Control System Control Speaker Select 1 24 Message Select 1 14 Diagnostic Select Trouble Silence Console Lamp Test Status Indicators visible with closed System Active green Control green Control green in Use green Zone 1 24 Active Zone 1 24 Fault to Page green Trouble yellow 1 8 Active red 1 8 Fault yellow Amplifier 1 8 Fault 1 8 Fault 1 8 Active Console Fault yellow Power green Fault yellow Fault yellow Fault yellow Bus Fault yellow Fault yellow Active g
