Notifier NWS-2 NOTI-FIRE-NET Web Server-2

NWS 2 Server 2 NOTI Web Server 2 NWS 2 is a web device that allows remote access to the NOTIFIER fire network via the Internet or an intranet With the NWS 2 users can view fire alarm control panel FACP event device properties and other information in a web page data available on the NWS 2 is a of the data on NOTI network at the time the browser the information and with the Event Refresh Time fea enabled the NWS 2 will automatically refresh the Event with any new events In addition the same event informa can be sent via email to a select group of users simulta NWS 2 communicates to NOTI version 5.0 higher and then interfaces to the Internet Intranet using IP based wire Ethernet connection Use VeriFire Tools 4.0 or higher to make the necessary network configu settings which allow the web server to communicate an Internet browser Access to a text status display of NOTI and the properties remotely via the Internet or an intranet Automatically send up to 50 emails or cell phone text mes in response to any system event Compatible with NOTI version 5.0 and higher Standard Ethernet over IP TCP IP connection Your business network remains secure by installing the behind your network firewall Explorer style user interface Supports standard Microsoft Internet Explorer 5.0 or higher VeriFire Tools version 4.0 or higher support for remote of the NWS 2 with ONYX NFS 640 NFS NFS2 3030 NCA NCA 2 Event Refresh if enabled allows the event list to refresh at the specified time interval 3 to 90 seconds Unacknowledged Beep feature if enabled causes the browsing the NWS 2 to beep at three second if there are unacknowledged events in the Multiple List Supports up to 64 operator and 64 administrator accounts Built in password security and user access record Online Authorization log keeps a record of the user name and date of the last 50 users to access the system Multiple users can access the web server at the same time No fire alarm control functions are permitted The NWS 2 an ancillary device and not intended for primary reporting NWS 2 is compatible with NOTI version 5.0 higher for the following panels and devices ONYX Series NFS NFS2 3030 and NFS 640 AM2020 AFP1010 version 5.0 SIB NET AFP 200 version 5.0 NAM events only AFP 300 400 version 5.0 NAM BACnet Gateway events only NFN NION events only A0 141 Systems Board Welcome Screen NFN Web Server NCS Network Control Station events only NCA Network Control Annunciator events only NCA 2 Network Control Annunciator events only DVC Digital Voice Command The NWS 2 is NOT intended as a primary annunciator and ancillary in nature voltage range 18 VDC to 24 VDC current 330 mA 24 VDC Operating temperature 32 to 120 0 to 49 Mounts on a CHS 4L chassis in a CAB 3 Series see data DN 3549 or CAB 4 Series cabinet see data sheet Direct connection to NFS 640 and NFS NFS2 3030 fire control panels NCM W or NCM F required for con to NOTI 12 29 06 Page 1 of 2 Listings and Approvals listings and approvals apply to the NOTI Server 2 In some cases certain modules or applications not be listed by certain approval agencies or listing may be process Consult factory for latest listing status UL ULC Listed file S635 Information NOTI Web Server 2 Includes PC board suppressor P N PNET 1 DB9 to NUP cable P N NUP to 24 V power cable 75583 and mounting plate required components NCM W or NCM F for connection to NOTI PC with Windows XP 2000 98 or NT 4.0 or higher and an available serial port required programming DB 9 to DB 9 null modem cable required for programming VeriFire Tools version 4.0 or higher required for programming Standard Ethernet network cable with RJ45 connectors Architecture Browser or or NCS NION Gateway NCS NION Gateway NION NOTIFIER and VeriFire are registered trademarks and is a trademark of Honeywell International Inc Microsoft Windows are registered trademarks of Microsoft Corporation IBM is a trademark of IBM Corporation by Honeywell International Inc All rights reserved Unauthorized use of document is strictly prohibited document is not intended to be used for installation purposes We try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice more information contact Notifier Phone 203 484 7161 FAX 203 484 7118 in the U S A 2 of 2 DN 7113 12 29 06
