ONYXWorks Lite Systems Interface Lite is the next generation in life safety sys for monitoring fire over a proprietary network The Lite system is designed to provide clear and annunciation of fire system events The preciseness that annunciation enables the responding personnel to the location of a life safety event quickly and accu ONYXWorks Lite software is a high performance graphi interface capable of displaying all network events and The workstation uses Microsoft Windows 10 64 Enterprise The operator is presented with a consistent and operation for all monitored equipment The ONYX Lite software has the ability to monitor up to four Noti Fire Alarm Control Panels and is an ideal addition to a network when network monitoring and are required Supported NOTIFIER Equipment 4 nodes maximum NFS 320 NFS2 640 NFS2 3030 Notifier 8th edition Fire Alarm Control Panels Notifier legacy panels Operates under Microsoft Windows 10 64 bit Enter Supports the following additional languages Korean Portuguese French Spanish Chinese Traditional and Simplified ONYXWorks Lite is not listed with UL FM or CNTC INTERFACE Customizable interface provides flexibility to display infor as desired Dynamically generated floor plan overview provides point reference when using the zoom function Global Zoom Level for devices 0 100 definable by administrator Device information including point address and descrip can be quickly accessed through icon left click func Navigational tree icons and configurable areas provide access to system floor plans Systems NOTIFICATION AND RESPONSE Graphic and text display of all off normal events Six states can be visually represented for each input Normal Trouble Fire Alarm Pre Alarm detec Disabled and Security Automatic screen navigation configurable to the device in based on event priority Multimedia text audio video and bitmaps can be linked any device providing instructions to operators for event Operator log with response tracking SETUP Graphic Editing mode allows on site or off site system building floor plan CAD drawings as a dxf wmf jpg or gif Customizable device icon and colors to visually represent event type User defined icons can be globally defined PNG BMP JPG and GIF formats ACCESS System Administrator definable user profiles provide strict of access Monitoring and Control profiles delineate defined operator Operator Login Logout Change Password feature allows authorized personnel to access the system Logs in history of any operator changes in the workstation Macros provide customizable programming to simplify tasks disable enable de activate activate device control and system information through right click function History Manager Filterable history reporting serves as a maintenance and diagnostic tool to identify pat 1 24 2017 Page 1 of 2 MAINTENANCE Backup capability for screen member and history data Obtain software version numbers for network panels Series fire panels Upload Download databases to NOTIFIER ONYX series and perform panel upgrades ONYX Series only the network using VeriFire Tools Monitoring ONYXWorks Lite system is an ideal component of a Fire Center for real time fire system status and system options ONYXWorks Lite interfaces directly to a fire system using an NCS interface board NCS interface board is an intelligent interface used by ONYXWorks Lite system that facilitates monitoring and of up to four nodes of NOTIFIER fire panels The NCS board is available in two versions PC based gate wire and fiber versions Line Information REQUIRED HARDWARE USER PROVIDED with Intel i7 4700EQ 2.4GHz QM87 4th Gen four threads 6 MB of Cache 16 GB of RAM a 240 GB hard drive sound mouse keyboard Ethernet PCI slot RS 232 serial COM port Windows 10 64 ORDERING INFORMATION ONYXWorks Lite software user manuals on configured USB Hardlock software key and NCS interface board for wire network ONYXWorks Lite software user manuals on configured USB Hardlock software key and NCS interface board for fiber network UL approved printer see data sheet DN 6861 see data sheet DN 6971 PC network wire card included with OW PC network fiber card included with OW OW Lite Version 4 Software KeyBit Required Version 4 Monitoring version 5.0 network Lite ONYX Series Alarm Control Panels is a trademark and NOTIFIER VeriFire and Lite are registered trademarks of Honeywell International Inc and Windows are registered of Microsoft Intel is a registered trademark of Intel Corporation by Honeywell International Inc All rights reserved Unauthorized use this document is strictly prohibited document is not intended to be used for installation purposes We try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice more information contact Notifier Phone 203 484 7161 FAX 203 484 7118 in the U S A 2 of 2 DN 60404 D 1 24 2017
