RLD Remote Display RLD is a mimic annunciator for the NOTIFIER INSPIRE fire alarm control panels FACP or NCD Network Control This provides the FACP or NCD with remote serially con display A five inch touchscreen display provides system sta point information and event counters The display shows two simultaneously and pages through up to 50 of the highest events in the system The RLD also provides system control six programmable softtouch buttons as well as Acknowledge Reset and Drill N16 FACP supports a maximum of 5 RLDs configured as a These take up one of the 10 available router addresses The annunciators may be a mix of ACM 30 and RLD units Each will occupy one address The RLD does not support annunciators Five inch high definition touchscreen display Programmer key switch for user authentication providing the to enable the control inputs for acknowledge silence and drill Configurable control buttons that are operational only when key Six programmable buttons each with a descriptor label status and configurable action on off disable enable Supervision of remote power supply Field programmable using VeriFire Tools and interactive touch is unlocked Acknowledge Silence Reset Drill controls USB C Connection Compatibility N16 Series NCD Options AIO power limited two wire serial communication with N16 or control panels Remote Display RLD mounts in a standard 3 gang electrical box External con are the AIO serial communications 24 VDC power input earth ground between the RLD and control panels occurs over a 2 wire AIO serial interface This communication is by the fire alarm control panel Each RLD also requires a 24 VDC power connection Loss of power to the RLD as a communication failure at the control panel The RLD also be powered from a power limited and regulated remote supply listed for fire protective signaling use A 10 12 2021 Page 1 of 2 SPECIFICATIONS Input Power VDC 200 mA WEIGHT 2 lbs 0.91 kg 7 in 17.8 cm W 5.75 in 14.6 cm H 1 In 2.54 cm D AND HUMIDITY RANGES system meets NFPA requirements for operation at 0 49 120 and at a relative humidity 93 2 RH noncondensing at 2 90 3 However the useful life of the system s batteries and the electronic components may be adversely by extreme temperature ranges and humidity Therefore it recommended that this system and its peripherals be installed in environment with a normal room temperature of 15 27 LISTINGS AND APPROVALS file number s below reference the specific listings for the mod in this document In some cases certain modules or applica may not be listed by certain approval agencies or listing may in process Consult NOTIFIER for latest listing status UL Listed S635 FM Approved CSFM 7165 0028 0516 FDNY listings and approvals below apply to the RLD In some certain modules or applications may not be listed by certain agencies or listing may be in process Consult factory for listing status UL 864 10th edition NFPA 72 National Fire Protection Association Alarm Panel power Reference Circuit from panel to five RLD can connected to N16 FACP Configuration document is not intended to be used for installation purposes try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice INSPIRE is a trademark of and NOTIFIER is a registered of Honeywell International Inc by Honeywell International Inc All rights reserved Unauthorized of this document is strictly prohibited of Origin USA Clintonville Road CT 06472
