SpectrAlert SP2C Series Speaker Strobes Sensor SP2C Series Speaker Strobes combine strobe and speaker technology with a design intended for ceiling mount applications SpectrAlert SP2C ceiling speaker strobes the low current draw of the ceiling mount SpectrA strobes with the intelligible fidelity sound quality of the SP200 Series evacuation speaker Like all SpectrAlert products the SP2C Series speaker strobes feature the flexibility to meet a wide of applications The 24 volt strobe is available in six candelas including 177 candela for sleeping areas speaker offers field selectable 25.0 70.7 voltage and 1 4 1 and 2 watt power taps The SP2C Series ceiling speaker strobes offer design that is sensitive to the aesthetic demands of ceiling applications The round shape maintains a low profile similar to that of a smoke detector Its stylish and design further refine the aesthetics over other wall ceiling mount designs Yet SpectrAlert round provides clearly visible identification from all The SP2C Series ceiling speaker strobes several features to simplify installation By incorporat the SP200 Series speaker the entire unit may be mounted a standard 4 x 4 x 2 1 8 101.6 x 101.6 x 53.975 mm without an extension ring An optional backbox skirt also available for surface mount applications With SpectrA round shape aligning the backbox with the room walls not necessary SpectrAlert always lines up Combines SpectrAlert ceiling mount strobe and speaker for low current draw fidelity sound quality 24 volt models available with 15 15 75 30 75 95 115 177 candela strobes 25.0 and 70.7 volt speaker with four field selectable power Ceiling specific shape profile and aesthetics Strobe is synchronizable with MDL Sync module Mounts to a 4 x 4 x 2 1 8 101.6 x 101.6 x 53.975 mm without an extension ring Round shape offers greater placement flexibility 6.8 172.72 mm diameter 4 x 4 x 2 1 8 101.6 x 101.6 x 53.975 mm back Operating Temperature 32 to 120 0 to Operating Voltage 24 VDC and FWR unfiltered Terminals 12 to 18 AWG 3.25 to 0.75 mm J 113 Devices Voltage Range 24 volts 16 33 volts Voltage Range with Sync Module 24 17 33 volts Voltage 25.0 or 70.7 volts nominal Terminals 12 to 18 AWG 3.25 to 0.75 mm Range 400 4,000 Hz The SP2C Series is UL listed from 400 to 4,000 Hz but will an output from 100 to 10,000 Hz Taps 1 4 1 2 1 and 2 watts OUTPUT 10 Feet W W W 1 4 W Reverberant Anechoic Assumes flush mount installation speaker strobe shall be a System Sensor Model listed to UL 1480 and UL 1971 and be approved for protective signaling systems Speaker shall be capable of at 25.0 or 70.7 nominal Vrms and shall have a fre range of 400 to 4,000 Hz Speaker shall have power which are selected by shunts The strobe shall comply the NFPA 72 requirements for visible signaling appli flashing at 1 Hz over the strobe entire operating volt range The strobe light shall consist of a xenon flash tube associated lens reflector system LISTINGS AND APPROVALS listings and approvals apply to the modules specified in document In some cases certain modules or applica may not be listed by certain approval agencies or listing be in process Consult factory for latest listing status UL Listed S4048 MEA Listed 63 00 E 15 15 75 30 75 95 cd models 115 177 cd models CSFM 7320 1653 143 7 31 08 Page 1 of 2 INFORMATION WITH DRAW No Max Operating Current RMS Max Operating Current RMS Speaker Back Skirt Surface Mount Skirt Accessory Skirt is a registered trademark and Sync is a trademark of International Inc by Honeywell International Inc All rights reserved Unauthorized use this document is strictly prohibited document is not intended to be used for installation purposes We try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice more information contact Notifier Phone 203 484 7161 FAX 203 484 7118 in the U S A 2 of 2 DN 6797 A 7 31 08
