SWIFT Wireless AV Base NOTIFIER SWIFT AV bases WAV CRL WAV CWL WAV RL WAV WL are intended for use with compatible System Sensor AV notification appliances to meet a comprehensive range notification requirements The AV Base provides power for the and visual signals and supports wireless communication with Fire Alarm Control Panel FACP The L Series AV notification is mounted directly to the wireless AV base allowing flexi in color placement and signal output is supplied through two sets of 4 batteries one set provides for wireless communication and the other set provides power the notification appliance audio and or visual signal Battery life the wireless portion is UL listed for at least 2 years Battery life for AV set of batteries depends upon the activation time and output of the audio or visual signal The AV base boosts output volt to support 24 VDC options on connected devices SWIFT synchronization module W SYNC can be used to pro audio and visual synchronization between SWIFT notification and System Sensor wired notification appliances The synchronization module operates from 24 V power with battery support and communicates through the mesh to the gateway and FACP Synchronization is only available notification appliances that use the System Sensor synchroni protocol Synchronization of the SWIFT notification appli within a single mesh network is inherent in the wireless and a wireless synchronization module is not needed The also provides wireless control and monitoring of a Notifica Appliance Circuit NAC expander or power supply SYSTEM OVERVIEW SWIFT Smart Wireless Integrated Fire Technology wireless sys offers intelligent addressable devices which provide secure communication to the Fire Alarm Control Panel FACP a Class A mesh network Wireless devices create an oppor for applications where it is costly concrete walls ceilings bur wires obtrusive surface mount conduit or possibly dangerous to use traditional wired devices It allows fast installation time critical situations and provides the flexibility to add wireless wired systems for retrofit installations Both wired and wireless can be present on the same FACP for an integrated solu mesh network within the SWIFT system creates a child parent between the devices so that each device has two par providing a second path for communications on every device If device can no longer operate for any reason the rest of the can still communicate with each other directly or through or more intermediate devices Once an initial mesh network is mesh restructuring automatically occurs to find the stron paths possible within the network Converts compatible System Sensor L Series AV appliances to wireless AV appliances Wireless installation Class A mesh network Addressable code wheels Commercial applications Listed to UL 464 UL 1638 and UL 1971 Frequency hopping Bi Directional Communications SPECIFICATIONS Dimensions Ceiling Diameter 7.4 19 cm Depth 1.6 4 cm Weight 20.0 oz 567 g installed with 8 batteries SPECIFICATIONS Maximum Transmit RF Power 17 dBm Radio Frequency Range 902 928 MHz Operating Humidity Range 10 to 93 Relative Humidity Operating Temperature Range 32 to 120 0 to 49 Battery Type 8 Panasonic CR123A or 8 Duracell DL123A Battery Life batteries 2 year minimum batteries See battery life table Battery Replacement Replace during annual maintenance or TROUBLE BATTERY LOW displays Information W BATCART Wireless battery cartridge 10 pack SMB500 WH White surface mount back box WAV CRL Wireless AV base ceiling red WAV CWL Wireless AV base ceiling white WAV RL Wireless AV base wall red WAV WL Wireless AV base wall white W SYNC Wireless sync module WAV RL WAV WL are compatible with wall mount L Series manufactured after 26 April 2019 date code 9045 and later and WAV CWL are compatible with all ceiling mount L Series 8 17 2020 Page 1 of 3 EQUIPMENT ULC listed models have all required languages UL ULC Red Wall Red Ceiling Red Ceiling English Red Ceiling French Strobe White Ceiling White Ceiling English White Ceiling French Strobe Red Wall Red Wall English Red Wall French Strobe White Wall White Wall English White Wall French White Ceiling White Ceiling English White Ceiling French White Ceiling Clear Lens Alert Red Wall Red Wall English Red Wall French Red Wall Plain Red Wall Fuego White Wall White Wall English White Wall French White Wall Amber Lens White Wall Clear Lens White Wall Plain Canadian model White Wall Sounder Red Ceiling Red Wall Sounder Red Wall Sounder White Ceiling White Wall Sounder White Wall 2 wire Red Wall 2 wire Red Wall English 2 wire Red Wall French Sounder Strobe Red Wall Strobe 2 wire Red Wall Plain Strobe 2 wire Red Wall Fuego Strobe 2 wire White Wall 2 wire White Wall English 2 wire White Wall French Sounder Strobe White Wall Strobe 2 wire White Wall Plain Strobe 2 wire White Wall Fuego Strobe 2 wire Red Ceiling 2 wire Red Ceiling English 2 wire Red Ceiling French Strobe 2 wire White Ceiling 2 wire White Ceiling English 2 wire White Ceiling French Red Ceiling Red Ceiling English Red Ceiling French Page 2 of 3 DN 61067 C cid 129 8 17 2020 BATTERY LIFE TEMPORAL 3 AMBIENT CONDITIONS Battery Life at Temporal 3 Ambient Conditions Life Minutes per Candela Setting at at at at cd cd cd at cd at cd at cd at cd at cd at cd cd 23m 51m 44m 45m 12m 35m 31m 34m 15m 15m 09m 09m 55m 44m 03m 54m 20m 02m 58m 41m 22m 14m 22m 39m 31m 28m 17m 24m life will decrease using continuous tone or other coded patterns and under non ambient environmental conditions 45m 56m 39m 54m 6m 39m 24m 46m 02m 18m 30m 11m
