FWD 200P FWD 200ACCLIMATE FWH 200ROR135 SWIFT Wireless Detectors wireless detectors are intelligent addressable detectors provide secure reliable communication to the Fire Alarm Con Panel FACP across a Class A mesh network Wireless detec create an opportunity for applications where it is costly walls ceilings buried wires obtrusive surface mount or possibly dangerous asbestos to use traditional wired In addition both wired and wireless devices can be present the same FACP providing an integrated wired wireless solution increased installation potential SWIFT detection line includes a photoelectric Acclimate fixed heat and rate of rise heat detectors The photoelec detectors transmit a digital representation of smoke density a wireless mesh to a gateway and on to a FACP The Accli detectors combine a photoelectric chamber and a 135 fixed heat detector Acclimate can also transmit an alarm sig due to heat per UL 521 The fixed heat detector and rate of rise utilize sensors designed for open area protection with 50 spacing capability as approved by UL 521 sensors offer addressable code wheels and two LEDs The LEDs controlled by the panels Operation modes include red green amber colors with various solid or blink patterns mesh network within the SWIFT system creates a child parent between the devices so that each device has two par providing a second path for communications on every device If device can no longer operate for any reason the rest of the can still communicate with each other directly or through or more intermediate devices SWIFT system also engages frequency hopping to prevent sys interference whether intentional or accidental devices communicate across the mesh network through a gate to the FACP The FACP views the SWIFT wireless device and addressable device on the system providing similar detec functions and outputs as a wired counterpart In addition both and wireless devices can be present on the same FACP to the needs of a given application A SWIFT wireless system use any combination of modules smoke and heat detectors and A V bases Wireless installation Class A mesh network Addressable code wheels Commercial applications UL 268 listed Frequency hopping Bi directional communications Control Panels NFS2 3030 NFS2 640 NFS 320 NFS 320SYS NFW 100X NFW 50X Wireless Detector with B210W Base OPERATING SPECIFICATIONS 2.4 inches 61 mm installed in B210W base 6.0 inches 152mm installed in B210W base Weight includes 4 batteries 9.2 oz 261 g installed in base Temperature Range Photo 32 to 120 0 to Acclimate with Heat 32 to 100 0 to 38 Velocity Acclimate with Heat 0 to 4,000 fpm 0 to 20 m sec Humidity Range 10 to 93 non condensing Ratings Fixed Temperature Set Point 135 57 Detection 15 8.3 SPECIFICATIONS Frequency Range 902 928 MHz SPECIFICATIONS Type 4 Panasonic CR123A or 4 Duracell DL 123A Life 2 years Replacement Upon BATTERY LOW or BAT LOW display during annual maintenance Listings and Approvals device complies with part 15 of the FCC rules meaning opera is subject to two conditions The device may not cause harmful interference and 2 The device accept any interference received including interference that cause undesired operation listings and approvals below apply to the basic intelligent wire detectors In some cases certain devices may not be listed by approval agencies or listing may be in process Consult fac for latest listing status 10 3 2018 Page 1 of 2 Listed S747 S1115 7272 0028 0271 7254 0028 0270 Approved ID AUBWFSSD ID 573X WFSSD and Codes SWIFT Wireless Intelligent Detectors comply with the following Standards and with NFPA 72 Fire Alarm System requirements 864 268 Devices and Ordering Information FWD 200P FlashScan intelligent wireless photo detector one B210W base for installation Requires 4 CR 123A included FWD 200ACCLIMATE FlashScan wireless Accli heat and photo detector using combined heat and smoke information and the ability to automatically adjust sensitiv based on ambient changes in the environment Requires one base for installation Requires 4 CR 123A batteries FWH 200ROR135 FlashScan intelligent wireless rate of rise heat detector Requires one B210W base for installation 4 CR 123A batteries included FWH 200FIX135 FlashScan intelligent wireless fixed tempera 135 heat detector Requires one B210W base for installa Requires 4 CR 123A batteries included FWSG FlashScan Wireless SWIFT Gateway 1 SWIFT Gate is required for each wireless mesh and supports up to 49 detectors or modules Connects to the SLC loop of a panel using FlashScan protocol Power may be sup by the SLC circuit or via an optional 24VDC input Use of the 24VDC input may be more convenient for service as it for powering down a gateway without shutting down an SLC loop FW MM FlashScan wireless monitor module Used to monitor with mechanical contact actuation Includes a special with a built in tamper magnet Recommended for installa in a SMB500 WH box ordered separately rather than a backbox for best performance Requires 4 CR 123A bat included FW RM Wireless relay module for use with the FWSG wireless Includes a special cover with a built in tamper magnet for installation in an SMB500 WH box ordered rather than a metal backbox for best performance 4 CR 123A batteries included NBG 12WL Wireless addressable pullstation Requires 4 CR batteries included NBG 12WLSP Wireless addressable pullstation Spanish text 4 CR 123A batteries included WAV CRL WAV CWL SWIFT Wireless Addressable A V bases 8 CR 123A batteries included Requires a non com ceiling System Sensor L series notification device ordered W SYNC Wireless sync module Requires 4 CR 123A batteries SMB500 WH Optional surface mount backbox B210W Detector base used for wireless detectors Includes a magnet so that wireless devices can establish installed tampered states SWIFT Tools Programming and diagnostic utility Free download www notifier com For installation on a typically laptop PC an approved version of Windows See Minimum System for SWIFT Tools Requires the W USB radio dongle for communication with SWIFT Wireless devices W USB Wireless USB radio antenna dongle that plugs into the port of a PC running SWIFT Tools The W USB provides a link with SWIFT Wireless devices Clintonville Road CT 06472 document is not intended to be used for installation purposes try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice Plus FlashScan NOTIFIER System Sensor and are registered trademarks of Honeywell International Inc Micro and Windows are registered trademarks of Microsoft Corporation is a registered trademark of Duracell U S Operations Inc is a registered trademark of Panasonic Corporation by Honeywell International Inc All rights reserved Unauthorized of this document is strictly prohibited of Origin Mexico
