TM 4 Series Modules TM 4 Transmitter Module provides NOTIFIER NFS2 NFS 3030 NFS2 640 NFS 640 and the NFS 320 Fire Control Panels and NCA 2 and NCA Network Control with three reverse polarity outputs alarm trouble supervisory and one fire municipal box trip on a single PC The TM 4 is designed to meet NFPA 72 requirements for Protective Signaling Systems and Remote Station Pro Signaling Systems On each TM 4 module in a system use either the three outputs alarm trouble and supervisory or fire municipal box trip Maximum load for each reverse polarity output circuit is 15 24 VDC nominal All circuits are power cross rated and per UL 1950 requirements Mounts on CHS Series chassis and in panel module loca Diagnostic LEDs green for Power ACS Data Reception and Data Transmission yellow for Trouble 24 V for reverse polarity outputs Disconnect mechanism provides a means for inhibiting alarm changes which cause trouble indication for unit at the Alarm Control Panel FACP Operation of the discon mechanism will also create a trouble condition on the output circuits Option jumper combines alarm and trouble conditions onto circuit Approximately 4.375 11.11 cm wide by 6.875 17.30 cm Mounts onto any panel module location Temperature and humidity ranges This system meets requirements for operation at 0 to 49 32 to and at a relative humidity noncondensing of 85 at 86 per NFPA and 93 2 at 32 2 89.6 1.1 per ULC However the useful life of the system batteries and the electronic components may be affected by extreme temperature ranges and Therefore it is recommended that this system and all be installed in an environment with a nominal room of 15 to 27 60 to 80 voltage range 18.0 to 31.0 VDC 24 V nominal Power requirements 165 mA Maximum current per output 15 mA three isolated outputs Supply voltage Sufficient capacitance provided to maintain minimum supply voltage for 20 ms during battery transfer a panel supply Current consumption 175 mA maximum 24 VDC G 310 Devices Transmitter Modules One isolated 24 VDC supply capable of driving a 45 mA three reverse polarity circuits 15 mA each OR one Box Trip Circuit 350 mA and support circuitry MUNICIPAL BOX TRIP Supervisory current 250 cid 2 A Trip current 0.35 A Coil voltage 3.65 VDC Wire resistance 3.0 ohms maximum TM 4 is designed to mount in CHS M2 CHS M3 CPU2 chassis CHS 4N or CHS 4L chassis onto a BMP 1 blank for dress panel mounting or in the ABS 8R cabinet Refer the TM 4 Product Installation Document number 51490 for information and diagrams CONNECTIONS to the TM 4 Product Installation Document number for diagrams and wiring information Highlights LEDS POWER green illuminates when 5 V is present on the TM 4 TROUBLE yellow illuminates when ACS Trouble occurs or if Disable All Outputs switch SW4 is on RX ACS green blinks when Annunciator Control System data is received TX ACS green blinks when ACS data is transmitted SW1 EOL Resistor switch must be set to ON when the is the last device on the ACS circuit 3 3 10 Page 1 of 2 SW2 SW3 ACS Address switches tens and ones posi SW4 Disable All Outputs switch disables all outputs Remote Station Trouble when turned ON a Trouble will display at FACP when on for ease of mainte SW5 four DIP switches with the following functions SW5.1 not used SW5.3 when set to ON if the Signal button at the panel is pushed after an alarm has been the Remote Station or Municipal Box output will A subsequent alarm will reactivate the output In legacy system applications this function is NOT for the AM2020 AFP1010 or the INA SW5.4 when set ON Alarm and Trouble signals are combined onto one out Remote Station Alarm SW6 Isolator switch isolates or non isolates the Municipal output CONTROL SYSTEM INTERFACE TM 4 communicates with the control panel over a power one channel multi drop EIA 485 serial interface using a poll response protocol TO COMBINE ALARM AND TROUBLE jumper allows the user to combine Alarm and Trouble condi on reverse polarity output 1 CAPABILITY selection switch allows the user to disconnect the TM 4 out inhibiting the transmission of signals to the remote monitor station except for trouble conditions Listings and Approvals listings and approvals apply to the TM 4 In some cases modules or applications may not be listed by certain agencies or listing may be in process Consult factory latest listing status UL Listed file S635 ULC Listed file CS118 NFS 640 NFS 3030 MEA approved files 317 01 E NFS 640 345 02 E NFS 232 06 E NFS2 3030 CSFM approved files 7165 0028 214 NFS 640 7170 NFS 640 7165 0028 224 NFS 3030 NFS2 7170 0028 223 NFS 3030 NFS2 3030 FM approved U S Coast Guard approved file 161.002 42 1 NFS 640 Lloyd Register type approved file 02 60007 NFS 640 City of Chicago approved City of Denver approved FDNY approved COA 6025 NFS2 640 COA 6026 Line Information Transmitter Module for NFS2 3030 NFS 640 NCA 2 and NOTIFIER are registered trademarks of Honeywell Interna Inc by Honeywell International Inc All rights reserved Unauthorized use this document is strictly prohibited document is not intended to be used for installation purposes We try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice more information contact Notifier Phone 203 484 7161 FAX 203 484 7118 in the U S A 2 of 2 DN 6860 A1 3 3 10
