Notifier VESDA-HLI-GW VESDA Gateway with VHX-1420-HFS

VESDA HLI GW Gateway VHX 1420 HFS VESDA Gateway provides a communication link between Xtralis VESDAnet network and the NOTI cid 129 FIRE cid 129 NET NFN via the VHX 1420 HFS High Level Interface The VESDA HLI GW translates VESDAnet protocol to protocol enabling events on the VESDAnet to be annunci on compatible fire network annunciators VESDA HLI GW connects to the standard or high speed and enables event notification and control VESDA detectors on the VESDAnet through a supervised VHX 1420 HFS notifications for up to 100 detectors are displayed on the network annunciators with a device type of can be initiated from these annunciators VESDA HLI GW Communicates with the VHX 1420 HFS using Modbus pro via RS 232 connection Supervises the communications to the VHX 1420 HFS Monitors up to 100 detectors Displays VESDA detectors as type on the dis nodes Monitors VESDAnet detector events from NCA 2 LCD 160 and NFS2 3030 configured for Network Dis Mode Controls VESDAnet detector functions from NCA 2 ONYX or NFS2 3030 configured for Network Display Performs Read Status of VESDAnet detectors from NCA 2 ONYXWorks and NFS2 3030 configured for Net Display Mode Enables zone mapping Provides DCC mode as required for Canadian applications The VESDA HLI GW translates VESDAnet protocol to NFN enabling events on the VESDAnet to be annunci on compatible fire network annunciators including detailed feature information see the VESDA HLI GW and Operation Manual High speed NOTI cid 129 FIRE cid 129 NET network Standard NOTI cid 129 FIRE cid 129 NET network 9th edition Fire Alarm Control Panels NFS 320 NFS2 640 NFS2 3030 NCA 2 Network Control Annunciator ONYXWorks Workstation PC NFN Gateways NFN GW PC F NFN GW PC W NFN NFN GW PC HNSF NFN GW PC HNW Embedded NFN Gateway NFN GW EM 3 NOTI cid 129 FIRE cid 129 NET Web Server NWS 3 LCD 160 Verifire Tools The VESDA Gateway is compatible with the following detectors VESDA VLF VESDA VLC Systems VESDA VLP VESDA VLS VESDA VLI VESDA E VEP VESDA E VEU VESDA E VEA equipment may exist on the network For the com list of compatible equipment and minimum release ver see the VESDA HLI GW Listing Document Power input 24 VDC Input current 460 mA 24 VDC or without Network Communications Module Temperature 0 to 49 32 120 Relative Humidity 93 non condensing at 32 It is recommended that this product be installed in an envi with a normal room temperature of 15 27 C 60 80 F Line Information detailed information about required components see the Installation and Operation Manual ordered from Notifier made in USA except VHX 1420 HFS VESDA Gateway Includes circuit board and required cables Requires VHX 1420 HFS a Network Com Module and a Network Display Node NCA 2 or NFS2 3030 in Network Display Mode all separately Also requires a customer supplied com and Ethernet network cable see specifications below in USA VESDAnet Network Interface Card Includes Connector Network Communications Module wire version Network Communications Module fiber version High Speed Network Communications Module cable interface 6 12 17 Page 1 of 2 High Speed Network Communications fiber optic cable interface multi mode High Speed Network Communications Mod twisted pair wire interface High Speed Network Communications fiber optic cable interface multi mode fiber to sin fiber High Speed Network Communications wire and fiber optic cable interface wire multi High Speed Network Communications wire and fiber optic cable interface wire single SUPPLIED BY CUSTOMER Computer PC running Microsoft Internet Explorer 8 or later with the latest version of Java to configure VESDA HLI GW Ethernet cable Standard Ethernet network cable with to RJ45 connectors VESDA Detectors Order directly from Xtralis and Codes and VHX 1420 HFS comply with the fol standards and requirements NFPA 72 National Fire Alarm Code UL 864 9th Edition Control Units Fire Alarm Systems CAN ULC S527 11 3rd Edition for Control Units for Fire Systems CAN CSA C22.1 VESDA HLI GW only UL 2017 1st Edition General Pur Signaling Devices and Systems CAN ULC S559 13 2nd Edition for Equipment for Fire Sig Receiving Centres and Systems VHX 1420 HFS only CAN ICES 003 Listings and listings and approvals apply to modules specified in this document some cases certain modules or appli may not be listed by certain agencies or listing may be in Consult factory for latest listing UL ULC S635 Detector Detector Detector Detector HLI Node ONYX and ONYXWorks are registered trademarks and is a trademark of Honeywell International Inc Windows a registered trademark of Microsoft Corporation VESDA is a registered and Xtralis is a trademark of Xtralis Pty Ltd by Honeywell International Inc All rights reserved Unauthorized use this document is strictly prohibited document is not intended to be used for installation purposes We try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice more information contact Notifier Phone 203 484 7161 FAX 203 484 7118 2 of 2 DN 60753 B cid 129 6 12 17
