Potter AIB Addressable Isolator Base

Features integrated into base restoring Amber LED indication of short circuit Maximum standby current 325 Maximum alarm current 1.85 mA includes a 5 year warranty 7165 0328 0194 Addressable Isolator Base 6 AIB comes with an integrated isolator module included The base has a locking feature for the that may be used or removed in the field Once the head is removed the isolator is accessible in the bottom of the unit isolator will open the Signaling Line Circuit down stream when a short circuit is detected This will provide devices between control panel and the isolator to continue to operate The short is indicated by a steady amber LED and once the short is the unit will return to normal operation Base Mounting should be mounted directly on the electrical box The mounting holes are configured for a single gang double gang octagon 4 square box Feature include a locking feature that prevents removal of the detector and removal of the base cover without using a tool To eliminate this feature break off the locking tab refer to Figure 1 and then install the detector 1 Eliminate the Locking Feature the plastic tab by twisting it toward a center the plastic tab by twisting it toward a center the base of the base To remove the detector from the base once the locking feature has been activated insert a small screwdriver into the slot on the to push the plastic tab while simultaneously turning the detector head counter clockwise refer to Figure 2 2 Removing of detector head from base a small bladed screwdriver to the locking tab Electric Signal Company LLC St Louis MO Cust Service 866 240 1870 Tech Support 866 956 1211 Canada 888 882 1833 www pottersignal com 1 OF 2 8830009 REV C06 13PRINTED IN USAAIBAddressABle IsolAtor BAsefirealarmresources com To remove the base cover from the lower enclosure once the locking feature has been activated insert a small screwdriver into slot on the on the base to push the plastic tab while simultaneously turning the detector head counter clockwise refer to 3 3 Removing of base cover from the lower enclosure tab Working voltage range for SLC current for SLC 1 current Include indicator indicator SLC wiring style of wiring after an AIB in Style 4 of wiring between an AIB and the next AIB in Style 6 or 7 Maximum number of AIB per SLC Loop 4 6 and 7 Maximum number of addressable devices connected to an AIB Operating relative humidity range Color temperature range 2 Dimensions without detector to 24.0 V mA D C max LED yellow Style 4,6 and 7 max max of points of panel divided by 8 of points of control panel units to 120 0 to 49 to 93 Non condensing White inches 54.4mm inches 150mm The standby current is the current that the device consumes when the device is in a non activated condition and where no current is transmitted to the fire alarm control panel FHA with AIB should be installed under 120 Installation temperature range of AIB is 32 to 120 specifications are subject to change without notice For further information contact Potter Electric Signal Company Support 2 OF 2 8830009 REV C06 13PRINTED IN USAAIBAddressABle IsolAtor BAsefirealarmresources com
