APS SA DA Pull Station Action Single or Dual Action versions Durable die cast construction Reset key matches the fi re alarm control panels Compatible with all PFC 6000 PFC 8000 and P Series panels Product includes a 5 year warranty Numbers APS SA Addressable Pull Station Single Action 1430810 APS DA Addressable Pull Station Dual Action 1430811 APS SA DA is compatible with Potter PFC 6000 series and addressable fi re alarm control panels It is a non coded pull station available in either a single or dual action and installs on a single box or surface mounts using the P32 BB P32 DBB deep back box APS SA Single Action is activated by simply pulling the white bar handle down The APS DA Dual Action is activated by the front cover and then pulling the white bar handle down activated the bar cannot be reset without opening the front Opening the front cover will also activate the pull station To the APS Series use the Potter WS 93 key to unlock and open the cover Once the cover is open push the bar back into the position and re secure the front cover Speci cations Voltage SLC Standby Current SLC Alarm Current 24.0 VDC Limitations Humidity Range Options Weight 120 0 49 Only H x 3.25 W x 1.75 D 93 non condensing gang box or P32 BB DBB 1.22 lbs 1.46 lbs Electric Signal Company LLC St Louis MO Tech Support 866 956 1211 Customer Service 866 572 3005 www pottersignal com REV B 10 14 PAGE 1 OF 2 the Address APS Series uses one SLC address which must be assigned prior to installation of the device The address is set using either the handheld device or the device addressing feature built into each Potter fire alarm control panel Station Front View Station Back View and Wiring FACP OR PREVIOUS DEVICE NEXT DEVICE WIRED PAGE 2 OF 2 8830052 REV B 10 14Potter Electric Signal Company LLC St Louis MO Tech Support 866 956 1211 Customer Service 866 572 3005 www pottersignal comAPS SA DAAddressable Pull Station Single Dual Actionfirealarmresources com
