Features or Dual action versions Durable die cast construction UUKL Listed for Smoke Control key matches the fire alarm control panels with Ipa Series panels Class a Class X Class B includes a 5 year warranty paD100 pSSa Single action is activated by simply pulling white bar handle down The paD100 pSDa Dual action activated by lifting the front cover and then pulling the white handle down Once activated the bar cannot be reset without the front cover Opening the front cover will also activate the station To reset the paD100 pS Series use the potter WS 93 key unlock and open the front cover Once the cover is open push the bar back into the normal position and re secure the front cover paD100 pSSa pSDa is compatible with potter Ipa and aFC series addressable fire alarm control panels It is a non coded pull station available in either a single or dual action and installs on a single gang box or surface mounts using the or p32 DBB deep back box Specifications Voltage SLC Standby Current SLC alarm Current VDC 200ua 120 0 49 Only H x 3.25 W x 1.75 D 93 non condensing gang box or p32 BB DBB 1.22 lbs 1.46 lbs Limitations Humidity Range Options Weight page 1 OF 2 Pull StationSingle Dual Action8830097 REV D 12 18Potter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comfirealarmresources com the Address paD100 pS Series uses one SLC address assigned to the device The address is set using the DIp switch located on the back of the paD100 pS Station Front View 1 POTTER Station Back View and Wiring 2 POTTER WIRED CONTACTS FACP OR DEVICE NEXT DEVICE Information pull Station Single action pull Station Dual action No page 2 OF 2 REV D 12 18Potter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comPAD100 PSSA PSDAAddressable Pull StationSingle Dual Actionfirealarmresources com
