CA2Z A INITIATING MODULE Listed Option for use with the PFC 4410RC Series Protected In 5.1k End Of Line Resistor Board Assembly Mounts to PFC 4410RC Panel stand offs No 3006013 Model CA2Z Class A Module is designed to be used with the PFC Fire Control Releasing Panel to convert from two Class B device circuits to two Class A circuits module is to be mounted in the upper right hand corner of the panel to the panel is made via the 8 pin header mounted on the side of the CA2Z Typical Wiring 1 2 3 4 BOARD 1 2 3 4 2 USED 1 3527 11 Electric Signal Company 2081 Craig Road St Louis MO 63146 4161 Phone 800 325 3936 Canada 888 882 1833 www pottersignal com IN USA 5401025 REV F 1 OF 1
