CAM A INDICATING CIRCUIT MODULE Listed Option for use with the PFC 4410RC Series Protected Requirements In Alarm 25 mA at 24VDC from control panel indicating circuit In Polarized 5.1k End Of Line Resistor number 3005300 Model CAM Class A Module is designed to be used with the Fire Control Releasing Panel to convert a single Class indicating appliance circuit to a Class A circuit one module is for each indicating appliance circuit After installing the the indicating circuit should be activated to ensure proper and connections module is provided with double sided foam tape and should mounted in the area below the main circuit module so that the are accessible Typical Wiring BAR NO NO IF USED 1 2 2 3 4 INDICATING CIRCUIT POLARITY IS FOR ALARM REMOVE RESISTOR 927 15 Electric Signal Company llC 2081 Craig Road St louis MO 63146 4161 Phone 800 325 3936 Canada 888 882 1833 www pottersignal com IN USA 5400927 REV l PAGE 1 OF 1
