Potter HUSK-20 Latching Hold-Up Switch

File Preview
File Preview
Click below to download for free

File Data

Name potter-husk-20-latching-hold-up-switch-1250394687.pdf
Type PDF
Size 862.07 KB

Text Preview

A Brand HOLD UP SWITCH Form C contact Metal housing Key reset Silent operation Status window indicator armed alarmed Mechanical operation Terminals for easy wiring HUSK 20 is a mechanical hold up switch designed for silent operation It is activated by using one finger to press down on the switch activated the switch mechanism locks insuring an immediate alarm signal A status window designed on top of the hold up switch its condition RED alarmed and BLUE armed To reset the HUSK 20 use the key provided The housing is made of metal and is gray hold up switch sends a signal to a dedicated 24 hour hold up circuit of a burglar control panel That signal in turn will send the immediate to police or central station Wiring N O COM Common Normally Close Normally Open End Of Line Resistor Rating DC DC AC Terminals Range 18 176 80 Electric Signal Co LLC St Louis MO Cust Service 866 240 1870 Tech Support 866 956 1211 Canada 888 882 1833 www pottersignal com IN USA 8850046 REV C 1 OF 1
