Potter IDC-6 Initiating Device Circuit Expander

Features Mounts with included stacker bracket May mount in panel accessory cabinet ae 2 ae 8 or ae 14 Cabinets or the pSN 1000 e power Supply provides 6 IDC Input Circuits Maximum 31 IDC 6 per panel Maximum p Link wire length of 20 feet Initiating Device Circuit expander IDC 6 provides an 6 inputs per module The panel supports up to thirty one IDC 6 modules The circuits are power limited and supervised inputs are suitable to monitor 2 wire smoke detectors Smoke shall be installed in compliance with NFpa 72 Inputs can be used for automatic manual waterflow or supervisory service IDC 6 communicates via the p Link communication bus IDC 6 can be mounted in either the control panel cabinet the power supply ae 2 ae 8 or the ae 14 expander cabinet card is mounted to the exclusive Stacker Bracket for secure and mounting IDC 6 is connected to the fire control panels using a 4 wire RS connection The connection is power limited and supervised The must be mounted in either a compatible fire alarm panel the or within 20 feet of the panel or power supply using the ae 8 or the ae 14 expander cabinet each card is mounted to exclusive Stacker Bracket for secure and accessible mounting Specifications Standby Current alarm Current PWR Standby Current PWR Alarm Current Zone Wiring Zone Capacitance Zone Short Circuit Temperature Humidity Range no of IDC 6 panels ma ma ma maximum Standby ma maximum alarm ohms max mF max ma to 120 0 to 49 C non condensing 4 x 6 x 1 1 8 Series AFC ARC Series page 1 OF 2 Initiating Device Circuit ExpanderPotter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal com8830140 REV E 11 19firealarmresources com A P Link and IDC Power Wiring B P Link and IDC Power Wiring Module Class A Left or Class B Right Wiring Example Open Contact Part K EOL Open Contact or Smoke Detector 1 2 3 4 5 6 1 2 3 4 5 6 Information Expander No page 2 OF 2 Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal com8830140 REV E 11 19IDC 6 Initiating Device Circuit Expanderfirealarmresources com
