Potter PAM-1 Multi-voltage Relay Module

File Preview
File Preview
Click below to download for free

File Data

Name potter-pam-1-multi-voltage-relay-module-0547261398.pdf
Type PDF
Size 1.06 MB

Text Preview

Features Single SPDT relay with LED Double sided adhesive tape Mounting screw Six 12 leads 18 AWG 6 wire nuts PAM 1 Relay provides 10.0 A form contacts The relay be energized by one of three input voltages 24VDC 24VAC 120VAC The input voltages are polarity sensitive and diode PAM 1 Relays contain a red LED which indicates when the coil is energized PAM SD may be mounted by using the double sided adhesive the self drilling screw or loosely placed in an electrical backbox Relays are ideal for applications where remote relays are required fire alarm control or status feedback They are only suitable for use UL864 applications and installed in accordance with NFPA 70 NFPA 72 Specifications to 120 0 to 49 Rating 38mm H x 1.20 31mm W x 0.77 20mm D 304.8mm 18 ga wire leads at 120 VAC at 24VDC Microamps at 5VDC 24VDC 50mA 24VAC and 120VAC recognized SPDT Information Relay Module No PAGE 1 OF 1 Relay Module8830164 REV B 2 21Potter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comfirealarmresources com
