Potter RCDS Series Releasing Circuit Disable Switch

Features Meets requirements of NFPA 72 and 2001 Colored LEDs indicate system status Stainless steel plate mounts to single gang box RCDS 1 key removable in both positions RCDS 2001 key only removable in enabled position to comply NFPA 2001 Compatible with any 24VDC system device consists of a stainless steel faceplate green LED amber and a switch assembly It is designed to mount on a standard gang electrical enclosure RCDS 1 complies with the requirements of NFPA 72 National Alarm and Signaling Code RCDS 2001 complies with the requirements of NFPA 2001 on Clean Agent Fire Extinguishing Systems Specifying a physical switch to disconnect the release circuit in of a software controlled disconnect Creating a supervisory condition on the associated release panel Specifications Rating 3 4 W x 4 1 2 H x 2 D Approximate on single gang or handy box AMP 40 VDC VDC 10mA use only range 22 to140 to 60 PAGE 1 OF 2 SERIESReleasing Circuit Disable Switch5401214 REV F 10 17Potter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comfirealarmresources com Connect the red and black leads to the 24 VDC auxiliary power terminals on the release panel Be certain to observe polarity Connect the yellow wires to the supervisory zone on the panel green LED indicates the RCDS is in the Normal condition and release circuit is enabled amber LED indicates that the release circuit is disabled Information Releasing Circuit Disable Switch Circuit Disable Switch Agent No connection for the supervisory circuit has 4 wires 2 yellow and gray The 2 yellow wires are for connection to the supervisory The 2 gray wires are for connection to additional devices or the EOLR for the supervisory zone PAGE 2 OF 2 REV F 10 17Potter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comRCDS SERIESReleasing Circuit Disable Switchfirealarmresources com
