Potter STAT-X Aerosol Generator Technical Bulletin

The following provides information when using Potter addressable panels with STAT X Aerosol Please refer to the appropriate wiring diagrams for proper installation P400R IPA Series and ARC 100 Addressable Releasing Control NAC circuits support up to ten 10 Stat X generators each Refer to wiring diagram 1 circuits cannot be used to release Stat X generators Intelligent Power Supply NAC circuits support up to ten 10 Stat X generators each Refer to wiring diagram 1 Addressable Output Module Each MOM 4 module supports one 1 Stat X generator Refer to wiring diagram 2 Addressable Output Module Used With IPA Series ARC 100 Panels PAD100 NAC module requires 24VDC power from an IPA or ARC 100 panel or PSN 1000 circuit A single NAC circuit can provide power for PAD100 NAC modules with a combined total of 10 generators as descibed in examples below Refer to wiring diagram 3 Examples One 1 PAD100 NAC module with ten 10 Stat X generators powered by a single NAC circuit Five 5 PAD100 NAC modules with two 2 Stat X generators each powered by a single NAC Ten 10 PAD100 NAC modules with one 1 Stat X generators each powered by a single NAC Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal com PAGE 1 OF 3 Aerosol Generator Technical Bulletinfirealarmresources com Diagram 1 Diode Resistor Assembly 1 2 3 This configuration doesn provide short supervision of the circuit segments for 1 Generator 2 A short on these will not initiate a trouble condition the releasing control panel Diagram 2 Releasing STAT X aux power loop This configuration doesn provide of open circuits beyond the of the E match protection device open circuit on the red black wires of protection device will not initiate a trouble on the releasing control panel No 24 S Electric Signal Company Output Module No MOM 4 No xxxxxx TN51318e date XX XX 2009 supply for terminals 24 and 24 must power limited Terminals are power limited A Module E match Device Diode Resistor Assembly Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal com PAGE 2 OF 3 Aerosol Generator Technical Bulletinfirealarmresources com Diagram 3 This configuration doesn provide of open circuits beyond the of the E match protection devices open circuit on the red black wires of protection device will not initiate a trouble on the releasing control panel Also short on the circuit segment to generator 2 not initiate a trouble condition on the control panel 1 2 Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal com PAGE 3 OF 3 Aerosol Generator Technical Bulletinfirealarmresources com
