Cerberus Pyrotronics CT-35 Temporal Code Module 3068

System 3TM Control Module AND ARCHITECT SPECIFICATIONS CT 35 CT 35 Code Module Dual Inputs Mulitple Signal Circuit Control ANSI S3.41 Audible Emergency Signal Placement Supervised Solid State Circuitry Listed ULC Listed Temporal Code Module Model CT 35 is designed to a common coded signal to connected alarm bells chimes lamps etc via Alarm Extender Type AE 30U or AA 30U Actuation of the module from a high going DC signal between 12 and 24 volts system common from any type ZU Zone Module or main control panel Actuation may also be manual from type SM Switch Module Dual input actuation terminals provided to facilitate programming module contains sold state circuitry to supply output 15 ma maximum at a controlled Code 3 Temporal as per ANSI S3.41 American National Standard Emergency Evacuation Signal These signals in can control up to three 3 audible signal circuits AE 30U and AA 30U modules or other output By adding type SR Supplementary Relay Mod additional audible circuits can be actuated Audible power is not provided by the CT 35 Module Model CT 35 is placement supervised providing a trouble signal upon removal from the system unit is Underwriters Laboratories Inc and ULC listed Information Requirement 60 mA Input 24 VDC 5mA Output 24 VDC 15mA max Information Code Module to Installation Instruction P N 315 095020 NUMBER Wiring Terminal 39 40 of CP 35 10,11 of CP 30 Pyrotronics Ridgedale Avenue Knolls NJ 07927 201 267 1300 201 397 7008 in U S A Pyrotronics East Pearce Street Hill Ontario 1B7 CN 905 764 8384 905 731 9182 1996 Issue
