Cerberus Pyrotronics LED-8 16 Hard Wired Annunciators 7305

LED 8 16 Series Wired Annunciators for SXL PXL MXL System 3 AND ARCHITECT SPECIFICATIONS 8 and 16 Zone Displays Lamp Test Switch Option Trouble Indication with Silence Available Black or Red Enclosure Yellow LED for Supervisory Indication NYMEA and CSFM LED 8 and LED 16 Series remote annunciators provide indication of alarm and supervisory conditions for any Pyrotronics fire alarm system The zone LED are in red with spare yellow LED for supervisory These annunciators are driven by relays in the fire control panel addition to zone annunciation the annunicators are with an option Model suffix which provides a lamp test a trouble buzzer and a local trouble silence with ring back Each annuciator comes ready for or flush mounting the 8 and 16 zone models are UL Listed and approved CSFM and NYMEA The installation instructions detail connections to Cerberus Pyrotronics MXL PXL SXL System 3 fire alarm controls Information Number 8 Zone Annuniator Red Zone Annuniator Black Zone Annunciator with Lamp Trouble Red Zone Annunciator with Lamp Trouble Black Zone Annunciator Red Zone Annunciator Black Zone Annunciator with Lamp Trouble Red Zone Annunciator with Lamp Trouble Black refer to Installation Instructions 315 095690 NUMBER Diagram Diagram Pyrotronics Ridgedale Avenue Knolls NJ 07927 201 267 1300 201 397 7008 www cerbpyro com in U S A Pyrotronics East Pearce Street Hill Ontario 1B7 CN 905 764 8384 905 731 9182 1997 Issue
