Cerberus Pyrotronics MH and MHT Mini-Horns Horn and Horn-Strobes 2534

MH and MHT Mini Horns and Horn Strobes AND ARCHITECT SPECIFICATIONS Single Two Gang 4 or Surface Back Mounting Both Steady Horn and Code Models ADA UL 1971 Horn Strobe Screw Terminals Accept up 12 AWG Available in Red or Off Color Listed Pyrotronics horns and horn strobes provide high electronics for maximum reliability and low current to meet any fire life safety application units are designed for ADA applications and meet latest requirements of NFPA 72 the National Fire Alarm and UL 1971 standards for signaling devices for the impaired Pyrotronics Mini Horns are available in both 4 x 2.75 x 1.33 deep and universal 4.75 x 4.75 x 1.33 deep configurations The mounting version mounts to either a single gang 4 inch square or surface box With the universal models the horn horn strobe mounts to the univer mounting plate with a single screw On all units only terminal strip protrudes from the back of the horn for mounting in virtually any depth box The MH a steady tone horn The MHT uses a jumper to steady or temporal Code 3 horn Mounting Gang Mounting Mounting w Strobe strobe versions utilize a Xenon flashtube with solid state for maximum reliability and efficiency Strobes are in 15 15 75 75 and 110 Candela ratings The top the strobe has a rounded dome shape made of clear The overall lens height is 2.5 with a width of 1.25 S15 model provides 15 cd and is used in non sleeping where lower candela is required per UL 1971 S17 model is for non sleeping installations requiring cd output while also providing an ADA compliant 75 cd output for public areas S75 version offers a 75 cd polar output that meets requirements for regular lighted public areas while satisfying UL 1971 in substitution of multiple 15 cd S110 version intensifies a non sleeping ADA area with cd and can be used in sleeping areas to help wake hearing impaired person per UL 1971 NUMBER and Horn Strobes 24 VDC No Rating Strobe Current Ratings mA 15cd 75cd 110cd represents strobe model e g 15 17 75 or 110 MH Series has steady horn ONLY MHT is user selectable steady or temporal Wiring Wiring 6 32 x 5 8 6 32 5 8 8 32 1 2 x 1 1 4 Mount MH S U MHT S U next Device or Style W Y B Circuits Return to FACP X Z Class Circuits No Jumpers to Power Signal and Strobe Separate Circuits Box Red 4 SQ Large Box Red for Universal Mount Models When ordering signals or boxes in white add the letter W to the end of the number e g MH S15 U is MH S15 UW in white next Device or Style W Y B Circuits Return to FACP X Z Class Circuits The use of other than Cerberus Pyrotronics notification appliances detectors and with Cerberus Pyrotronics control equipment will be considered a misapplication of Pyrotronics equipment and as such void all warranties either expressed or implied regard to loss damage liabilities and or service problems Pyrotronics Ridgedale Avenue Knolls NJ 07927 201 267 1300 201 397 7008 www cerbpyro com in U S A Pyrotronics East Pearce Street Hill Ontario 1B7 CN 905 764 8384 905 731 9182 1997 Issue Polarity from Panel Previous Polarity from Panel Previous Notification Circuit Notification Circuit
