Cerberus Pyrotronics RCC-1 Remote Command Center 5039

ENGINEER AND ARCHITECT SPECIFICATIONS Command Center Remote MKB for Display and Control 80 Character LCD Display Auto Backlight Supertwist High Resolution Full Command Keypad MXL Network Interface Style 4 or Style 7 Metal Enclosure with Keylock Door Restricts Keypad Access Optional Printer Peripheral Interface PIM 1 Supervised ULC Listed FM CSFM NYMEA City of Chicago Approved RCC 1 is a full control remote command and center for use with the MXL It includes the a PS 5N7 power supply and local interface and a small sheet metal enclosure a lockable door The door restricts access to the and control keypad located on the RCC 1 RCC 1 is connected to the MXL local network and powered by the system power supplies or other listed supplies such as the PS 35 or Alarm Saf AS PS5 BFS 24UL The RCC 1 is capable of connected to the MXL local network in either 4 or Style 7 wiring configurations Located inside RCC 1 enclosure the PS 5N7 modules acts as an to the MXL network and also supplies the 5 VDC to the unit Adjacent to the PS 5N7 are studs for a PIM 1 modules The addition of a to the RCC 1 allows the connection of a printer PAL 1 VDT Color Graphics MXL G MXL GT or peripherals to four RCC 1s may be operated in a fully super mode Additional RCC 1s can be used and in a non supervised mode equipment is approved for operation over the range of 0 to 49 and Architect Specifications the use of the RCC 1 keypad the operator may events silence audibles and reset the The menu driven display allows the listing to the and optional printing of a wide range of data the detector voltages sensitivity settings log system status and more In addition pass access allows the operator to perform control and functions such as changing smoke detector sensi settings disarming input and output devices controlling relays executing display and lamp walk test etc Access to the keypad controls is by a locked enclosure door The only keys without opening the door are the HOLD and display control keys As an option a GenBox WD lens may be inserted instead of the metal cover in the door This permits viewing of the full and keypad but does not allow access to any of keys The RCC 1 is shipped with the sheet metal in the door NUMBER Information No Command Center Lens for RCC 1 Door Instructions Data Wiring Configuration Pyrotronics Ridgedale Avenue Knolls NJ 07927 201 267 1300 201 397 7008 in U S A Pyrotronics East Pearce Street Hill Ontario 1B7 CN 905 764 8384 905 731 9182 1996 sheet dated 5 95
