Cerberus Pyrotronics RemCon Remote Control Module 9353

ENGINEER AND ARCHITECT SPECIFICATIONS Remote Control Module Remote Acknowledge Reset or Same User Interface as Control Key Switch Activated 16 Module Capacity on IXL Network Listed ULC Listed FM CSFM and NYMEA Approved RemCon remote control module features the ability to acknowledge or reset the IXL system or conduct fire drill The RemCon provides a remote user interface functions in the same way as the IXL control panel maximum of sixteen RemCon modules can be installed the IXL communication network system use of the RemCon is ideal in situations where the control panel is not conveniently accessible or having the control functions of the fire system is at a remote location example of the RemCon installation and use is when an is installed in a school utility room but control of the is required in a principal or administrator office this way the responsible person may be able to remotely silence or reset an alarm or remotely a fire drill RemCon module has a key switch that enables or the module It also has LED for Power Alarm Supervisory condition Bypass or Bell Silence Service Required and Polling module LED blinks periodically to show the system supervision that is polling of the module RemCon also features LEDs and corresponding keys for Acknowledge Reset Drill RemCon is equipped with a sounder horn If desired sounder horn can be disabled and Architect Specifications Remote Control Module for use with the IXL System be model RemCon The RemCon shall remotely reset or drill the IXL system The RemCon interface shall function in the same way as the IXL panel maximum of sixteen RemCon modules may be installed the IXL communication network system NUMBER RemCon module shall have a key switch that enables disables the module It also shall have LEDs for Power Trouble Supervisory condition Bypass or Bell condition Service Required and Polling module LED shall blink periodically to show IXL system supervision that is polling of the module RemCon shall also have LEDs and corresponding keys for Acknowledge Reset Drill RemCon shall be equipped with a sounder horn If the sounder horn can be disabled Configuration use a RemCon module on a system it is necessary to and enable the module in the IXL computer configuration software For details reference the Programming Manual Address Programming the RemCon module address by entering the mode from the IXL panel and applying the to the appropriate place on the module front Data Characteristics RemCon Acknowledge Reset and Drill function keys operational only when the operator inserts and the RemCon key switch using the control panel key Diagram the RemCon in a 411 16 x 411 16 x 21 8 backbox Con the system wiring to the screw terminals on the module Connections power network communication Return line wire power connections the RemCon module to a 4 11 16 inch by 2 1 8 inch electrical backbox If an auxiliary power supply is be sure J2 is in position To disable the sounder move and open the safety pin jumper SW5 wiring polarity when making connections Dam may result from incorrect wiring Information No No Remote Control Semi flush Trim Black The use of other than Cerberus Pyrotronics detectors and bases with Cerberus control equipment will be considered a misapplication of Cerberus Pyrotronics and as such void all warranties either expressed or implied with regards to loss liabilities and or service problems Pyrotronics Ridgedale Ave Knolls NJ 07927 201 267 1300 201 397 7008 in U S A Pyrotronics East Pearce Street Hill Ontario 1B7 CN 905 764 8384 905 731 9182 1994 sheet dated 8 93
