System 3 Control Modules AND ARCHITECT SPECIFICATIONS RM 30U 30RU RM 30U 30RU Device Module Device Module FM Approved Suitable for Systems Dioxide Systems Systems Sprinkler Systems Control Control Listed CSFM NYMEA Approved Releasing Device Modules Models RM 30U and RM are designed to operate and supervise solenoid valves relays used for release of extinguishing systems and to and supervise relays used for door closing opening fan control RM 30U and RM 30RU are functionally the same except the RM 30RU incorporates three 3 series resistors that used to adjust the resistance of the circuit to compensate varying numbers of solenoids logic and subsequent activation of the modules are by appropriate zone and control modules in the 3 control panel modules are suitable for continuous duty when used with duty solenoids input signals are required for activation of these mod and a release takes place when a high going signal is on both of the input terminals These input signals compatible with the outputs available from the System 3 and control modules All agent release logic time etc are performed ahead electrically of the RM 30U by utilizing such System 3 modules as ZU 35 Zone PM 31 Program Matrix TL 30U Timer and SR 32 Module The separate release power input terminals the modules versatility and reduces the load on the conductor system bus circuit disconnect switch is provided to deactivate the during servicing of the system When the switch is in off position a trouble condition LED will be illuminated modules are provided with a yellow LED trouble indicator show an open release circuit condition when the system is in alarm The LED indicator can be lamp tested from the panel In addition all wiring is monitored by the control for ground faults The modules are placement super providing a trouble signal on removal from the system Specifications supervised release circuit for the extinguishing system system door control or fan control shall be by a Cerberus Pyrotronics Releasing Device NUMBER Model RM 30U 30RU This module shall be system by a ten pin plug and harness assembly and be operable with the main control panel receipt of the two high going input activation signals solid state circuitry shall apply power for the solenoid or 24 Vdc relay circuitry disconnect switch shall be provided to deactivate circuit during servicing of the system and shall indicate a condition when the switch is in the off position module shall contain a yellow LED indicator to indicate open release circuit when the system is in an otherwise condition The LED shall be lamp tested from the panel model RM 30U 30RU shall be placement supervised shall be Underwriters Laboratories listed and Factory approved Information current requirement supervisory 5 mA energized 1.5A maximum line resistance 3 ohms for typical approved load Information No Wt Device Module Releasing Device Module with Diagram The use of other than Cerberus Pyrotonics detectors and bases Cerberus Pyrotronics control equipment will be considered a of Cerberus Pyrotronics equipment and as such void all either expressed or implied with regards to loss damage and or service problems Pyrotronics Ridgedale Avenue Knolls NJ 07927 201 267 1300 201 397 7008 in U S A Pyrotronics East Pearce Street Hill Ontario 1B7 CN 905 764 8384 905 731 9182 1995 sheet dated 1 95
