Cerberus Pyrotronics TL-30U Time Limit Control Module 3166

ENGINEER AND ARCHITECT SPECIFICATIONS 3 Control Module Precision Timing LED Indicator Delayed Signal Capability Placement Supervised Solid State Logic Circuitry Listed and ULC Listed NYMEA CSFM and FM Approved Time Limit Module TL 30U is designed to provide a time interval from 6 seconds to 10 minutes after either a signal circuit is activated such as a alarm or a signal circuit is deactivated such as bells The module is also capable of repeating the operational sequence when a subsequent alarm is received in a system utilizing the Subsequent Feature module which is of solid state circuitry is normally drawing no power until an alarm signal is re When this occurs a binary counter is activated to precisely the length of the desired time limit before the pre programmed sequence of system This sequence could be for silencing audible devices so that the system could receive and subsequent alarms An alternate use would be sending of an alarm to municipal headquarters if the source had not been checked or controlled or it involve the actuation of an extinguishing system time interval is available in two ranges as follow 6 seconds to 20 seconds 30 seconds to 10 minutes units are preset for a 5 minute time out se but can be changed by field adjustment Underwriters Laboratories Inc standards require when time limit cutoffs are used with audible devices shall operate no less than 3 minutes and no more 10 minutes module contains a red LED indicator lamp that is at the end of the timing period This lamp will on until the module has been reset Model TL 30U module is placement supervised a system trouble signal upon removal from the unit is Underwriters Laboratories Inc listed and Architect Specifications for precise time control of an output signal by delaying actuation or stopping actuation shall be by a Cerberus Pyrotronics Time Limit Module TL 30U This module shall be system intercon by a ten wire jumper plug and harness assembly shall be operable with the system main control panel NUMBER time in time out duration period shall be capable of set at any precise interval between the time frames 6 seconds to 20 seconds and 30 seconds to 10 This interval shall be controlled by a solid state binary counter contained in the circuitry of the At the end of the time interval a red LED indicator shall indicate completion of the time cycle after a subsequent alarm can be received and pro in an identical manner The module shall be reset the main control panel model TL 30U shall be Underwriters Laboratories Inc Information Requirement None 45 mA Information No Wt Limit Module lb Wiring the TL 30U are two jumpers and one potentiometer on the component board used program the module IN TIME OUT JUMPER TIME SHORT TIME JUMPER whether TL 30U will be in or time out Connect jumper common and TO or TI timing period LT 30 10 min ST 6 20 sec jumper between common LT or ST potentiometer R13 500K for the exact time desired Cross zoning may be accomplished the use of zone operated relays The two zone are fed directly into the TL 30U terminals 1 and After the second zone has activated the TL 30U will as programmed in denotes delay time period before 3 goes high When SA 30 or cross are not used terminal 2 to 1 input output signals not The use of other than Cerberus Pyrotronics detectors and bases with Cerberus Pyrotronics control equipment will be considered a misapplication of Pyrotronics equipment and as such void all warranties either expressed or implied in regard to loss damage liabilities and or service problems Pyrotronics Ridgedale Ave Knolls NJ 07927 201 267 1300 201 397 7008 in U S A Pyrotronics East Pearce Street Hill Ontario 1B7 CN 905 764 8384 905 731 9182 1995 sheet dated 5 94
